NERP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 1/2 Tons NERP005L Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The NERP005L-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley is the ultimate solution for effortless load transportation. This high-quality hoist, available in Capacity 1/2 Tons, is designed to provide exceptional performance and reliability in any workspace. By combining the NERP005L Electric Chain Hoist with the PT push trolley, you can conveniently move heavy loads with ease. Whether you are working in a small workshop or need occasional relocations, this hoist and trolley combination offers a cost-effective solution for smooth and efficient operation.With a lift height of 10 feet, this electric chain hoist caters to a wide range of lifting needs. You can rely on its superior load handling capabilities to meet the demands of your workplace, improving overall efficiency and productivity.The NERP005L-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley is built to withstand heavy-duty applications. Its durable construction and reliable components ensure long-lasting performance, making it a worthwhile investment for any industry.Featuring a push trolley, this hoist allows for easy maneuverability, allowing you to transport heavy loads quickly and effortlessly. The push trolley design eliminates the need for manual lifting, reducing the risk of injuries and increasing workplace safety.Designed with user convenience in mind, this electric chain hoist with push trolley is easy to install and operate. Its ergonomic design and intuitive controls make load handling a breeze, saving time and effort on every job.Upgrade your workspace with the NERP005L Electric Chain Hoist with Push Trolley and experience the benefits of efficient load transportation. Trust in its reliable performance, versatility, and exceptional durability to enhance productivity and safety in your workplace. Invest in this superior hoist and trolley combination today and make your workplace more efficient.

Product Specifications

.

Part Number:

NERP005L-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 1,000 lb, 10 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

15 fpm

Housing Width:

13 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

7 1/2 in

Housing Length:

20 1/4 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 11/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

4 3/16 in

Body Length:

20 1/4 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

3 1/5 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

16 5/16 in

Load Capacity:

1,000 lb

Minimum Between Hooks:

17 1/8 in

Motor HP:

0.75 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

3.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

15 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Programmable by External Controls=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/4 hp

Headroom:

17 3/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

3.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

1.7 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
