NERP Electric Chain Hoist with Push Trolley 15' Lift-Capacity 1/4 Tons NERP003S Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The NERP003S-15 HARRINGTON Electric Chain Hoist with Push Trolley is an indispensable asset for enhancing the productivity and efficiency of any workshop environment. This powerful unit is engineered to streamline your load-handling tasks with ease, making it ideal for both small workshops and larger spaces.

With a remarkable lifting capacity of 1/4 tons, this hoist is versatile enough to handle an array of loads, from heavy machinery to smaller equipment. Its design ensures a smooth operation, minimizing strain and maximizing efficiency during lifting. The standout feature of the NERP003S-15 is its impressive 15-foot lift height, which provides the reach needed to access elevated spaces effortlessly. In compact work environments or expansive settings, this hoist ensures nothing is out of reach, giving you both convenience and control.

Crafted with durability in mind, the NERP Electric Chain Hoist withstands even the most demanding conditions. Its robust construction ensures reliable performance day in and day out, so you can depend on it for all your load transportation needs. The combination of strength and efficiency makes this hoist an ideal solution for regular use, whether you are moving materials or lifting equipment.

Affordably priced, the NERP003S-15 offers exceptional value, making advanced load-handling technology accessible without straining your budget. Transitioning from manual lifting to electric hoisting will not only save time but also enhance workplace safety and productivity.

Step into a new realm of material handling with the NERP003S-15 HARRINGTON Electric Chain Hoist with Push Trolley. Experience the benefits of reliable efficiency and improve your workshop operations today. This high-performing tool is your partner in achieving greater heights in load transportation.

Product Specifications

.

Part Number:

NERP003S-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 500 lb, 15 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

36 fpm

Housing Width:

13 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

6 5/8 in

Housing Length:

18 13/16 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 11/16 in

Body Depth:

6 5/8 in

For Minimum Beam Height:

3 in

Body Length:

18 13/16 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

3 1/5 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

15 19/32 in

Load Capacity:

500 lb

Minimum Between Hooks:

15 5/8 in

Motor HP:

0.75 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

11 ft

Amps @ Low Volts:

3.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

36 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/4 hp

Headroom:

15 19/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

3.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

1.7 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
