NERP-FG Electric Food Grade Chain Hoist with Push Trolley 20' Lift-Capacity 1/4 Tons NERP003L-FG Electric Chain Hoist with Push Trolley HARRINGTON
Write a Review
Write a Review
HARRINGTON HOIST
NERP-FG Electric Food Grade Chain Hoist with Push Trolley 20' Lift-Capacity 1/4 Tons NERP003L-FG Electric Chain Hoist with Push Trolley HARRINGTON
$8,458.53
$6,631.34
(You save
$1,827.19
)
SKU:
NERP003L-FG-20-20
Condition:
New
Availability:
In stock
Weight:
188.90 LBS
Shipping:
Free Shipping
Part Number:
NERP003L-FG-20
Color:
White
Hoist Lift:
20 ft
Product:
Electric Chain Hoist, 500 lb, 20 ft, Push Trolley, White=Hoist Mount=Push Trolley
Includes:
Chain Container, Quick Disconnect Plugs On Pendant and Power Cord
Lift Speed:
15 fpm
Housing Width:
8 1/2 in
Manufacturers Warranty Length:
10 yr Brake Warranty, 3 yr
Housing Depth:
16 5/16 in
Housing Length:
13 13/16 in
For Minimum Beam Flange Width:
2 9/32 in
For Maximum Beam Flange Width:
4 in
For Maximum Beam Height:
Not Applicable
MFR Warranty Length:
1 yr
Body Width:
8 1/2 in
Body Depth:
16 5/16 in
For Minimum Beam Height:
3 3/16 in
Body Length:
13 13/16 in
Minimum Radius Curve:
43 5/16 in
Maximum Lifting Length:
20 ft
Controller Cord Length:
16 ft
Trolley Wheel Diameter:
2 23/64 in
Lifting Hook Opening Width:
16 5/16 in
Minimum Retracted Length:
16 5/16 in
Load Capacity:
500 lb
Minimum Between Hooks:
16 5/16 in
Motor HP:
0.75 hp
Phase:
3
Standards:
ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70
Voltage:
230/460V
Fits Brand:
Harrington Hoists Inc
Lubrication:
Food Grade Oil
Reeving:
1
Thermal Protection:
Yes
Control Cord:
16 ft
Amps @ Low Volts:
3.4 A
Number of Speeds:
1
Trolley Configuration:
Push Trolley
Trolley Speed:
Not Applicable
Features:
FDA Approved Food-Safe Oil, Grease and Lubricants
Lifting Hook Material:
Carbon Steel
Includes Clutch:
Clutch Included
Overload Protection Included:
Yes
Brake Type:
DC Current
Chain Grade:
Grade 80
Maximum Lift Speed:
Not Applicable
Included Components:
Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook
Fixed Lift Speed:
15 fpm
Clutch Type:
Friction
Minimum Lift Speed:
Not Applicable
Pendant IP Rating:
IP65
Chain Finish:
Nickel Plated
Controls:
Push Button Pendant=Mount Type=Push Trolley
Starts and Stops per Hour:
360
Duty Classification:
H4
Maximum Pulling Capacity:
Not Applicable
Number of Reeves:
1
Motor Horsepower:
3/4 hp
Headroom:
16 5/16 in
Includes Brake:
Brake Included
For Outdoor Use:
Yes
Lifting Hook Type:
Swivel Hook with Safety Latch
Maximum Lifting Capacity:
500 lb
Current at Minimum Voltage:
3.4 A
Trolley Wheel Material:
Steel
Current at Maximum Voltage:
1.7 A
Body Finish:
Epoxy Painted
Number of Load Chains:
1
Body Material:
Aluminum
Trolley IP Rating:
Not Applicable
Programmable:
Non-Programmable
Transform your food processing and packaging operations with the NERP003L-FG-20 HARRINGTON Electric Food Grade Chain Hoist with Push Trolley. Engineered specifically for the food industry, this hoist guarantees unparalleled performance and safety. With a robust lifting capacity of 1/4 to 2 tons, it provides the power needed to handle heavy containers and equipment with ease.
The 20-foot lift height offers exceptional flexibility, allowing you to access and maneuver items efficiently within your workspace. It caters to the unique demands of food manufacturing, ensuring you can transport materials seamlessly throughout your facility. The integrated push trolley simplifies movement, allowing for easy adjustment and precise positioning of loads, which is particularly advantageous in high-volume environments.
Durability is a hallmark of the NERP003L-FG, crafted to withstand the rigorous demands associated with food applications. This electric hoist meets every industry standard, ensuring consistent performance in challenging conditions. With its reliable construction, you can rest assured knowing it will enhance productivity, streamline operations, and efficiently cater to your lifting needs.
Investing in the NERP003L-FG-20 isn‚t just about acquiring a tool; it‚ about elevating your entire operational workflow. By revolutionizing your lifting capabilities, this hoist enhances your efficiency and productivity, making it an invaluable asset in any food processing or packaging setup.
Choose HARRINGTON for superior quality and performance. Experience the profound impact the NERP003L-FG-20 Electric Food Grade Chain Hoist with Push Trolley will have on your food manufacturing processes, propelling your efficiency to new heights. Embrace innovation and elevate your operations today.
The 20-foot lift height offers exceptional flexibility, allowing you to access and maneuver items efficiently within your workspace. It caters to the unique demands of food manufacturing, ensuring you can transport materials seamlessly throughout your facility. The integrated push trolley simplifies movement, allowing for easy adjustment and precise positioning of loads, which is particularly advantageous in high-volume environments.
Durability is a hallmark of the NERP003L-FG, crafted to withstand the rigorous demands associated with food applications. This electric hoist meets every industry standard, ensuring consistent performance in challenging conditions. With its reliable construction, you can rest assured knowing it will enhance productivity, streamline operations, and efficiently cater to your lifting needs.
Investing in the NERP003L-FG-20 isn‚t just about acquiring a tool; it‚ about elevating your entire operational workflow. By revolutionizing your lifting capabilities, this hoist enhances your efficiency and productivity, making it an invaluable asset in any food processing or packaging setup.
Choose HARRINGTON for superior quality and performance. Experience the profound impact the NERP003L-FG-20 Electric Food Grade Chain Hoist with Push Trolley will have on your food manufacturing processes, propelling your efficiency to new heights. Embrace innovation and elevate your operations today.
