NERP-FG Electric Food Grade Chain Hoist with Push Trolley 15' Lift-Capacity 1/4 Tons NERP003L-FG Electric Chain Hoist with Push Trolley HARRINGTON
Write a Review
Write a Review
HARRINGTON HOIST
NERP-FG Electric Food Grade Chain Hoist with Push Trolley 15' Lift-Capacity 1/4 Tons NERP003L-FG Electric Chain Hoist with Push Trolley HARRINGTON
$8,153.53
$6,468.30
(You save
$1,685.23
)
SKU:
NERP003L-FG-15-15
Condition:
New
Availability:
In stock
Weight:
92.70 LBS
Shipping:
Free Shipping
Part Number:
NERP003L-FG-15
Color:
White
Hoist Lift:
15 ft
Product:
Electric Chain Hoist, 500 lb, 15 ft, Push Trolley, White=Hoist Mount=Push Trolley
Includes:
Chain Container, Quick Disconnect Plugs On Pendant and Power Cord
Lift Speed:
15 fpm
Housing Width:
8 1/2 in
Manufacturers Warranty Length:
10 yr Brake Warranty, 3 yr
Housing Depth:
16 5/16 in
Housing Length:
13 13/16 in
For Minimum Beam Flange Width:
2 9/32 in
For Maximum Beam Flange Width:
4 in
For Maximum Beam Height:
Not Applicable
MFR Warranty Length:
1 yr
Body Width:
8 1/2 in
Body Depth:
16 5/16 in
For Minimum Beam Height:
3 3/16 in
Body Length:
13 13/16 in
Minimum Radius Curve:
43 5/16 in
Maximum Lifting Length:
15 ft
Controller Cord Length:
11 ft
Trolley Wheel Diameter:
2 23/64 in
Lifting Hook Opening Width:
16 5/16 in
Minimum Retracted Length:
16 5/16 in
Load Capacity:
500 lb
Minimum Between Hooks:
16 5/16 in
Motor HP:
0.75 hp
Phase:
3
Standards:
ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70
Voltage:
230/460V
Fits Brand:
Harrington Hoists Inc
Lubrication:
Food Grade Oil
Reeving:
1
Thermal Protection:
Yes
Control:
11 ft
Control Cord:
11 ft
Amps @ Low Volts:
3.4 A
Number of Speeds:
1
Trolley Configuration:
Push Trolley
Trolley Speed:
Not Applicable
Features:
FDA Approved Food-Safe Oil, Grease and Lubricants
Lifting Hook Material:
Carbon Steel
Includes Clutch:
Clutch Included
Overload Protection Included:
Yes
Brake Type:
DC Current
Chain Grade:
Grade 80
Maximum Lift Speed:
Not Applicable
Included Components:
Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook
Fixed Lift Speed:
15 fpm
Clutch Type:
Friction
Minimum Lift Speed:
Not Applicable
Pendant IP Rating:
IP65
Chain Finish:
Nickel Plated
Controls:
Push Button Pendant=Mount Type=Push Trolley
Starts and Stops per Hour:
360
Duty Classification:
H4
Maximum Pulling Capacity:
Not Applicable
Number of Reeves:
1
Motor Horsepower:
3/4 hp
Headroom:
16 5/16 in
Includes Brake:
Brake Included
For Outdoor Use:
Yes
Lifting Hook Type:
Swivel Hook with Safety Latch
Maximum Lifting Capacity:
500 lb
Current at Minimum Voltage:
3.4 A
Trolley Wheel Material:
Steel
Current at Maximum Voltage:
1.7 A
Body Finish:
Epoxy Painted
Number of Load Chains:
1
Body Material:
Aluminum
Trolley IP Rating:
Not Applicable
Programmable:
Non-Programmable
NERP-FG Electric Food Grade Chain Hoist with Push Trolley 15' Lift-Capacity 1/4 Tons NERP003L-FG Electric Chain Hoist with Push Trolley HARRINGTON
$8,153.53
$6,468.30
(You save
$1,685.23
)
The NERP003L-FG-15 HARRINGTON NERP-FG Electric Food Grade Chain Hoist with Push Trolley is the ultimate solution for all your food processing and packaging needs. This electric chain hoist is specifically designed to meet the strict requirements and regulations of the food industry, guaranteeing the highest levels of safety and cleanliness.With a 15' lift and Capacity ranging from 1/4 to 2 tons, this hoist is capable of handling a wide range of loads. Whether you need to lift heavy containers, equipment, or packages, the NERP003L-FG-15 is up for the task. It has been meticulously designed to provide exceptional performance and reliability, ensuring that your operations run smoothly and efficiently.One of the standout features of this hoist is its sleek and durable build. Manufactured using only high-quality materials, it is built to withstand the rigorous demands of food-related environments. The hoist is resistant to corrosion and contamination, which means your products will remain safe and free from any potential hazards.The push trolley on this hoist allows for easy maneuverability and precise positioning. You can effortlessly move your load along the rail, making it easier to transport items from one location to another. This feature not only increases productivity but also reduces the risk of accidents or injuries.When it comes to electric chain hoists, Harrington is a name you can trust. With their extensive experience and expertise in the industry, they have developed a hoist that meets the highest standards of quality and performance. The NERP003L-FG-15 is designed to provide precise and reliable lifting, giving you peace of mind knowing that your operations are in good hands.In conclusion, when looking for a reliable and efficient electric chain hoist for your food processing or packaging applications, look no further than the NERP003L-FG-15 HARRINGTON NERP-FG Electric Food Grade Chain Hoist with Push Trolley. With its durable build, easy maneuverability, and exceptional performance, this hoist is the perfect choice for the food industry. Trust Harrington to deliver the reliability and precision you need to take your operations to the next level.
