NERP-FG Electric Food Grade Chain Hoist with Push Trolley 10' Lift-Capacity 1/4 Tons NERP003L-FG Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The NERP-FG Electric Food Grade Chain Hoist with Push Trolley NERP003L-FG is engineered to meet the rigorous demands of the food processing and packaging industry. With a lift capacity of 1/4 tons and a generous 10-foot lift height, this hoist is your dependable partner for elevating efficiency in any food-related operation.

Designed for seamless mobility, the push trolley mechanism enables effortless load handling, making it easy to transport ingredients, lift heavy containers, or reposition equipment within your workspace. Users will appreciate the ergonomic controls that ensure smooth operation, reducing physical strain and minimizing downtime. This innovative design significantly enhances workflow efficiency, allowing personnel to focus on what matters most‚ quality production.

HARRINGTON prioritizes safety and compliance, and the NERP003L-FG is no exception. Built to strict food-grade standards, it features a durable construction that ensures both reliability and hygiene. This hoist‚ design safeguards the integrity of food products throughout the handling process, fostering a clean and safe working environment.

Boasting a lift capacity range from 1/4 to 2 tons, the NERP003L-FG is versatile enough to cater to both small-scale and large-scale production needs. Its impressive lift height provides the flexibility required to access overhead storage or to maneuver within tight spaces in your facility.

Choosing the NERP003L-FG Electric Food Grade Chain Hoist means investing in a smarter, more efficient workflow that supports your production goals while meeting the highest quality standards. Experience the difference with HARRINGTON‚ commitment to excellence‚ where reliability, efficiency, and food safety converge to elevate your operations. Enhance productivity and exceed your customers‚ expectations with this exceptional hoisting solution.

Product Specifications

.

Part Number:

NERP003L-FG-10

Color:

White

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 500 lb, 10 ft, Push Trolley, White=Hoist Mount=Push Trolley

Includes:

Chain Container, Quick Disconnect Plugs On Pendant and Power Cord

Lift Speed:

15 fpm

Housing Width:

8 1/2 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

16 5/16 in

Housing Length:

13 13/16 in

For Minimum Beam Flange Width:

2 9/32 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

8 1/2 in

Body Depth:

16 5/16 in

For Minimum Beam Height:

3 3/16 in

Body Length:

13 13/16 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

2 23/64 in

Lifting Hook Opening Width:

16 5/16 in

Minimum Retracted Length:

16 5/16 in

Load Capacity:

500 lb

Minimum Between Hooks:

16 5/16 in

Motor HP:

0.75 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70

Voltage:

230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Food Grade Oil

Reeving:

1

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

3.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

FDA Approved Food-Safe Oil, Grease and Lubricants

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

15 fpm

Clutch Type:

Friction

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/4 hp

Headroom:

16 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

3.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

1.7 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
