NERP Electric Chain Hoist with Push Trolley 20' Lift-Capacity 1/4 Tons NERP003H Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The NERP003H-20 HARRINGTON Electric Chain Hoist with Push Trolley is engineered to elevate your material handling operations with unmatched efficiency and reliability. Perfectly suited for small workshops and intermittent lifting tasks, this electric chain hoist boasts an impressive lifting capacity of 1/4 tons, allowing you to tackle heavy loads with ease. Say goodbye to the strains of manual labor; this hoist system automates your lifting needs, prioritizing safety and efficiency in the workplace.

With a generous 20-foot lift capability, the NERP Electric Chain Hoist enables you to maneuver and transport cumbersome items across your workspace effortlessly. Its design encourages smooth movement, enhancing productivity as you can focus more on the task at hand rather than struggling with heavy equipment. The integration of a PT push trolley makes this hoist a cost-effective addition to your operations, offering the flexibility to move loads seamlessly and save valuable time.

Whether you're lifting heavy machinery or shifting materials, the NERP003H-20 is built to meet the demands of various applications. Its robust construction ensures durability and longevity, providing a dependable lifting solution that won't let you down. Designed with practicality at its core, this hoist system is not only affordable but also simple to operate, making it accessible for users of all experience levels.

Transform your material handling processes with the NERP003H-20 HARRINGTON Electric Chain Hoist with Push Trolley. Experience the ultimate convenience and operational excellence as you elevate your capabilities. Invest in this reliable hoist system today, and redefine the way you manage lifts and loads in your workspace, paving the way for increased efficiency and enhanced productivity.

Product Specifications

.

Part Number:

NERP003H-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Electric Chain Hoist, 500 lb, 20 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

53 fpm

Housing Width:

13 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

7 1/2 in

Housing Length:

20 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 11/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

3 in

Body Length:

20 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

20 ft

Controller Cord Length:

16 ft

Trolley Wheel Diameter:

3 1/5 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

16 5/16 in

Load Capacity:

500 lb

Minimum Between Hooks:

16 5/16 in

Motor HP:

1.2 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

16 ft

Finish:

Electrostatic Enamel

Amps @ Low Volts:

4.8 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

53 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

16 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

4.8 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

2.5 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
