NERP Electric Chain Hoist with Push Trolley 15' Lift-Capacity 1/4 Tons NERP003H Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The NERP003H-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley is designed to simplify your material handling tasks, making them more efficient and reliable. This versatile hoist can effortlessly lift and transport loads of up to 1/4 tons, accommodating a wide variety of items, from lighter equipment to heavier machinery. With a generous lift height of 15 feet, it allows for easy access to items positioned at different elevations, whether retrieving items from the ground or accessing materials on higher shelves.

A key feature of this electric chain hoist is its innovative push trolley system, which enables seamless mounting and maneuvering. This user-friendly design ensures smooth operation, allowing you to glide through your workspace effortlessly while maintaining load stability. The compact and robust construction of the hoist guarantees durability, making it well-suited for both professional and personal use, whether in small workshops or larger industrial environments.

Ease of installation is another highlight of the NERP003H-15. Its straightforward design means that you can quickly set it up and start lifting without extensive downtime or hassle. The combination of dependable lifting power and convenience makes this hoist and trolley an indispensable tool for any workshop or material handling operation.

Choosing the NERP003H-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley means investing in a solution that prioritizes efficiency and reliability. Its impressive lifting capabilities, coupled with a convenient push trolley, maximize your productivity while minimizing the physical workload. Elevate your lifting tasks with this exceptional hoist and trolley combination, the ultimate solution for doing more with less effort. Perfect for a variety of applications, it's the essential tool for anyone looking to streamline their material handling processes.

Product Specifications

.

Part Number:

NERP003H-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 500 lb, 15 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

53 fpm

Housing Width:

13 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

7 1/2 in

Housing Length:

20 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 11/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

3 in

Body Length:

20 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

3 1/5 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

16 5/16 in

Load Capacity:

500 lb

Minimum Between Hooks:

16 5/16 in

Motor HP:

1.2 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

11 ft

Amps @ Low Volts:

4.8 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

53 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

16 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

4.8 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

2.5 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
