NERP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 1/4 Tons NERP003H Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

Experience unparalleled lifting efficiency with the NERP003H-10 HARRINGTON Electric Chain Hoist with Push Trolley, offering a remarkable 10-foot lift capacity and capable of handling loads up to 1/4 tons. This innovative hoist is tailored to meet the demands of both small workshops and large-scale operations, ensuring heavy items are moved with ease and precision.

Engineered for superior performance, the NERP003H combines robust power with a compact design, making it a versatile solution for various industrial applications. The integrated push trolley allows for seamless maneuvering, enabling operators to transport loads effortlessly throughout the workspace without the risk of strain or injury.

Safety features are paramount in the design of the NERP003H, which boasts advanced mechanisms to deliver a secure lifting experience. Built-in safeguards assure reliable operation, allowing users to focus on their tasks with confidence. When lifting heavy loads, peace of mind is non-negotiable, and this hoist guarantees just that.

Durability is a hallmark of the NERP003H, constructed from high-quality materials that endure the rigors of demanding environments. This hoist is not merely a tool but a long-term investment, engineered to withstand the test of time while enhancing productivity.

Elevate your operational efficiency with this top-tier electric chain hoist and push trolley combination from HARRINGTON. The NERP003H-10 is designed to streamline your workflow, making it a must-have for businesses seeking reliability and excellence. Embrace convenience and affordability without compromising quality; elevate your lifting experience to unprecedented levels with the NERP003H Electric Chain Hoist with Push Trolley.

Product Specifications

.

Part Number:

NERP003H-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 500 lb, 10 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

53 fpm

Housing Width:

13 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

7 1/2 in

Housing Length:

20 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 11/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

3 in

Body Length:

20 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

3 1/5 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

16 5/16 in

Load Capacity:

500 lb

Minimum Between Hooks:

16 5/16 in

Motor HP:

1.2 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

4.8 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

53 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

16 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

4.8 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

2.5 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
