NER Electric Chain Hoist 15' Lift-Capacity 5 Tons NER050L Electric Chain Hoist HARRINGTON

Product Overview

The NER050L-15 HARRINGTON NER Electric Chain Hoist is engineered for efficiency and reliability, making it an indispensable tool in any industrial setting. With an impressive lifting capacity of 5 tons, this electric chain hoist is designed to tackle the most challenging lifting tasks, ensuring that heavy equipment and materials can be moved safely and efficiently.

This premium hoist offers a remarkable lift height of 15 feet, providing exceptional versatility and maneuverability when positioning loads. Whether you need to lift materials for construction, manufacturing, or maintenance, the NER050L-15 ensures that your operations run smoothly and efficiently. This hoist is a true asset for any demanding job site.

• 5-ton lifting capacity, suitable for the toughest industrial applications.
• 15-foot lift height for enhanced load positioning and efficiency.
• Advanced technology for smooth and reliable operation, reducing downtime.
• Durable design that withstands harsh environments and heavy use.
• Safety features, including overload protection, for secure operation.
• Intuitive controls for easy and precise lifting and lowering of loads.
• Compact and lightweight design for easy transport and storage.

Safety and reliability are paramount, and the NER050L-15 Electric Chain Hoist is designed with that in mind. The integrated overload protection feature allows users to operate the hoist without concern for overloading, ensuring that safety is never compromised. The intuitive controls help operators execute tasks with precision and confidence, making the hoist user-friendly for technicians and workers alike.

Built to last, the NER050L-15 will be your go-to hoist, providing continuous performance through various jobs and conditions. Its robust construction means you can rely on it day in and day out, maximizing your productivity without sacrificing safety or efficiency. Choose the NER050L-15 HARRINGTON NER Electric Chain Hoist for superior quality and excellent performance—experience the ultimate lifting solution designed to meet the demanding needs of your industry.

Product Specifications

.

Part Number:

NER050L-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 10,000 lb, 15 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Limit Switches, Plug-In Connections

Lift Speed:

11 fpm

Housing Width:

17 1/2 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

10 1/2 in

Housing Length:

29 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

17 1/2 in

Body Depth:

10 1/2 in

For Minimum Beam Height:

Not Applicable

Body Length:

29 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

33 1/2 in

Minimum Retracted Length:

33 1/2 in

Load Capacity:

10,000 lb

Minimum Between Hooks:

33 1/2 in

Motor HP:

4.7 hp

Phase:

3

Standards:

ASME B30.16, ASME HST-1, NFPA 70

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

2

Thermal Protection:

Yes

Control Cord:

11 ft

Amps @ Low Volts:

16.4 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

11 fpm

Clutch Type:

Friction

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Enamel

Controls:

=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

120, 240

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

2

Motor Horsepower:

4 3/4 hp

Headroom:

33 1/2 in

Includes Brake:

Brake Included

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

10,000 lb

Current at Minimum Voltage:

16.4 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

16.4 A

Body Finish:

Enamel

Number of Load Chains:

1

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
