NER Electric Chain Hoist 10' Lift-Capacity 5 Tons NER050L Electric Chain Hoist HARRINGTON

Product Overview

The NER050L Electric Chain Hoist by Harrington is engineered to elevate your lifting operations to new heights, combining strength, technology, and safety in a robust design. Built to tackle the toughest industrial challenges, this hoist provides an impressive lift capacity of 5 tons, making it a reliable partner for moving heavy machinery, equipment, or materials with ease.

Durability is at the forefront of the NER050L‚ design. Constructed from high-grade materials, it can endure the demands of repetitive heavy usage, ensuring a long lifespan and consistent performance. This electric chain hoist is perfect for environments where reliability and efficiency are paramount.

What sets the NER050L apart is its advanced technology. Designed with precision and control in mind, it allows operators to manage lifting tasks effortlessly, reducing the physical toll associated with manual lifting. Experience greater efficiency with streamlined operations, as this hoist allows you to complete tasks in less time, maximizing productivity across your projects.

Safety is a critical focus in the NER050L‚ engineering. Equipped with numerous safety features, it minimizes risks and prevents accidents, protecting both equipment and personnel during lifting procedures. With these systems in place, you can operate with confidence, knowing that safety is prioritized.

In summary, the NER050L Electric Chain Hoist by Harrington represents a powerful and efficient lifting solution tailored for industrial applications. Its outstanding performance, durable construction, cutting-edge technology, and unwavering commitment to safety can transform your lifting operations. Experience the difference this superior hoist makes and take your productivity to unparalleled levels with the NER050L Electric Chain Hoist.

Product Specifications

.

Part Number:

NER050L-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 10,000 lb, 10 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Limit Switches, Plug-In Connections

Lift Speed:

11 fpm

Housing Width:

17 1/2 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

10 1/2 in

Housing Length:

29 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

17 1/2 in

Body Depth:

10 1/2 in

For Minimum Beam Height:

Not Applicable

Body Length:

29 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

33 1/2 in

Minimum Retracted Length:

33 1/2 in

Load Capacity:

10,000 lb

Minimum Between Hooks:

33 1/2 in

Motor HP:

4.7 hp

Phase:

3

Standards:

ASME B30.16, ASME HST-1, NFPA 70

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

2

Thermal Protection:

Yes

Control:

6 ft

Control Cord:

6 ft

Amps @ Low Volts:

16.4 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

11 fpm

Clutch Type:

Friction

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Enamel

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

120, 240

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

2

Motor Horsepower:

4 3/4 hp

Headroom:

33 1/2 in

Includes Brake:

Brake Included

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

10,000 lb

Current at Minimum Voltage:

16.4 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

16.4 A

Body Finish:

Enamel

Number of Load Chains:

1

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
