NER Electric Chain Hoist 20' Lift-Capacity 3 Tons NER030C Electric Chain Hoist HARRINGTON

Product Overview

Built with durability and ruggedness in mind, the NER030C-20 HARRINGTON NER Electric Chain Hoist is the ultimate solution for heavy-duty lifting tasks. Whether you're working in construction, manufacturing, or any other industry that requires robust lifting equipment, this hoist is designed to exceed your expectations.With a lifting capacity 3 Tons, this electric chain hoist can handle even the most demanding loads. It features a 20-foot lift, providing ample vertical reach for various applications. Whether you need to move materials vertically or horizontally, this hoist offers versatility and efficiency.Reliability is at the core of the NER030C Electric Chain Hoist. Engineered with high-quality components, it delivers consistent and smooth operation for maximum productivity. You can trust this hoist to perform flawlessly even in the harshest working conditions, allowing you to focus on your tasks without worrying about equipment failure.What sets the NER030C-20 HARRINGTON NER Electric Chain Hoist apart is its innovative design and advanced features. It is equipped with a reliable and powerful motor that ensures efficient lifting performance. The hoist's chain guide provides proper alignment, minimizing wear on the chain and increasing its longevity. Its compact size and lightweight construction make it easy to transport and install, saving you time and effort.Safety is a top priority in any lifting operation, and Harrington understands this. The NER030C Electric Chain Hoist is equipped with safety features such as a brake system that ensures load control and prevents accidents. The hoist also features overload protection, safeguarding against potential damage.When you choose the NER030C-20 HARRINGTON NER Electric Chain Hoist, you're choosing a product that delivers unmatched performance and durability. With its outstanding lifting capacity, reliable operation, and robust construction, it is the ideal solution for any heavy-duty lifting application. Trust Harrington's expertise and let the NER/ER electric hoist revolutionize your lifting needs.

Product Specifications

.

Part Number:

NER030C-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Electric Chain Hoist, 6,000 lb, 20 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Limit Switches, Plug-In Connections

Lift Speed:

17 fpm

Housing Width:

16 13/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

9 1/2 in

Housing Length:

27 11/16 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

16 13/16 in

Body Depth:

9 1/2 in

For Minimum Beam Height:

Not Applicable

Body Length:

27 11/16 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

20 ft

Controller Cord Length:

9 3/16 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 13/16 in

Minimum Retracted Length:

30 29/32 in

Load Capacity:

6,000 lb

Minimum Between Hooks:

32 15/16 in

Motor HP:

4.7 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

2

Thermal Protection:

Yes

Control Cord:

16 ft

Finish:

Electrostatic Enamel

Amps @ Low Volts:

16.4 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Dual Speed VFD, Easy Access Suspension, Extreme Duty Motor, Secondary Brake, Smart Brake Technology, State-Of-The-Art Chain Technology, Unique Smart Limit Option

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

17 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Programmable by Internal Controls=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

2

Motor Horsepower:

4 3/4 hp

Headroom:

30 29/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

6,000 lb

Current at Minimum Voltage:

16.4 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

7.9 A

Body Finish:

Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
