NER Electric Chain Hoist 10' Lift-Capacity 3 Tons NER030C Electric Chain Hoist HARRINGTON

Product Overview

The NER030C-10 HARRINGTON NER Electric Chain Hoist 10' Lift is a superior solution for all your heavy-duty lifting requirements. This electric hoist is designed to perform at its peak even in the harshest job sites. Its durable construction and dependable components allow it to effortlessly handle Capacity 3 Tons .With its powerful motor, the NER030C-10 ensures excellent performance with every use. This hoist is engineered to withstand demanding conditions and deliver exceptional lifting capabilities. Whether you are working on a construction site, in a warehouse, or any rugged environment, this electric hoist is up to the task.Renowned for their expertise in the industry, Harrington designed the NER030C-10 with utmost precision. Its unparalleled durability and reliability ensure seamless operation, meeting even the most demanding lifting requirements day after day.The 10' lift capacity of this chain hoist allows you to tackle lifting tasks with ease. From heavy machinery to beams and other materials, the NER030C-10 can handle it all effortlessly. Its efficient design and superior functionality make it a trusted choice for professionals across various industries.Safety is a paramount concern when lifting heavy loads, and the NER030C-10 does not compromise on that. Equipped with a range of safety features, this hoist ensures smooth and secure lifting operations. Designed to minimize the risk of accidents, it provides peace of mind during your lifting tasks.In conclusion, if you need a reliable, durable, and efficient electric chain hoist, look no further than the NER030C-10 HARRINGTON NER Electric Chain Hoist 10' Lift. Its exceptional performance, robust construction, and adherence to safety standards make it the perfect choice for heavy-duty lifting in demanding conditions. Place your trust in Harrington's expertise and choose the NER030C-10 for all your lifting needs.

Product Specifications

.

Part Number:

NER030C-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 6,000 lb, 10 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Limit Switches, Plug-In Connections

Lift Speed:

17 fpm

Housing Width:

16 13/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

9 1/2 in

Housing Length:

27 11/16 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

16 13/16 in

Body Depth:

9 1/2 in

For Minimum Beam Height:

Not Applicable

Body Length:

27 11/16 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

10 ft

Controller Cord Length:

9 3/16 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 13/16 in

Minimum Retracted Length:

30 29/32 in

Load Capacity:

6,000 lb

Minimum Between Hooks:

32 15/16 in

Motor HP:

4.7 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

2

Thermal Protection:

Yes

Classification:

H4

Control Cord:

6 ft

Amps @ Low Volts:

16.4 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Dual Speed VFD, Easy Access Suspension, Extreme Duty Motor, Secondary Brake, Smart Brake Technology, State-Of-The-Art Chain Technology, Unique Smart Limit Option

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

17 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Programmable by Internal Controls=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

2

Motor Horsepower:

4 3/4 hp

Headroom:

30 29/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

6,000 lb

Current at Minimum Voltage:

16.4 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

7.9 A

Body Finish:

Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
