NER-FG Food Grade Electric Chain Hoist 15' Lift-Capacity 2 Tons NER020L-FG Electric Chain Trolley HARRINGTON

Product Overview

The NER020L-FG-15 HARRINGTON NER-FG Food Grade Electric Chain Hoist is engineered to revolutionize your food processing and packaging operations. This electric chain hoist boasts an impressive lift capacity of up to 2 tons and can elevate loads up to 15 feet, making it the ideal solution for a variety of demanding tasks. Designed with the specific needs of the food industry in mind, the NER-FG series prioritizes both performance and safety, ensuring that your operations remain compliant with stringent hygiene regulations.

Constructed to minimize the risk of contamination, this hoist is built from food-grade materials that facilitate easy cleaning and maintenance. Its innovative design prevents product damage, handling even the most delicate items with utmost care to retain their quality during lifting. Whether you’re moving bulk ingredients, packaging finished products, or conducting routine maintenance, the NER020L-FG ensures smooth and efficient operations without compromising on safety or speed.

The ease of use and reliable functionality of the NER020L-FG make it a valuable addition to any food processing facility. Say goodbye to the challenges posed by heavy lifting and the potential for costly delays. This electric chain hoist is engineered to streamline your workflow, enhancing productivity while protecting the integrity of your products.

Investing in the NER020L-FG-15 is a commitment to excellence in food processing. With features designed to meet the unique challenges of the industry, this electric chain hoist offers a seamless blend of efficiency, reliability, and safety. Elevate your operations to new heights with the HARRINGTON NER-FG Food Grade Electric Chain Hoist and experience the advantages of superior technology tailored to your needs. Make the smart choice for your facility today and see the difference in performance and reliability.

Product Specifications

.

Part Number:

NER020L-FG-15

Color:

White

Hoist Lift:

15 ft

Product:

Electric Food Grade Chain Hoist, 4,000 lb, 15 ft, Hook Mounted-No Trolley, White=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Quick Disconnect Plugs On Pendant and Power Cord

Lift Speed:

14 fpm

Housing Width:

11 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

22 5/8 in

Housing Length:

27 7/8 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

11 11/16 in

Body Depth:

22 5/8 in

For Minimum Beam Height:

Not Applicable

Body Length:

27 7/8 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

22 5/8 in

Minimum Retracted Length:

22 19/32 in

Load Capacity:

4,000 lb

Minimum Between Hooks:

22 5/8 in

Motor HP:

2.4 hp

Phase:

3

Standards:

ASME B30.16, ASME HST-1M, FDA Approved, RoHS Compliant

Voltage:

230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Food Grade Oil

Reeving:

1

Thermal Protection:

Yes

Control Cord:

11 ft

Amps @ Low Volts:

2.4 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

14 fpm

Clutch Type:

Friction

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Epoxy Painted

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

2 3/8 hp

Headroom:

22 5/8 in

Includes Brake:

Brake Included

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

4,000 lb

Current at Minimum Voltage:

2.4 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

2.4 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
