SKU:
NER020L-FG-10-10
Condition:
New
Availability:
In stock
Weight:
161.00 LBS
Shipping:
Free Shipping
Part Number:
NER020L-FG-10
Color:
White
Hoist Lift:
10 ft
Product:
Electric Food Grade Chain Hoist, 4,000 lb, 10 ft, Hook Mounted-No Trolley, White=Hoist Mount=Hook Mounted-No Trolley
Includes:
Chain Container, Quick Disconnect Plugs On Pendant and Power Cord
Lift Speed:
14 fpm
Housing Width:
11 11/16 in
Manufacturers Warranty Length:
10 yr Brake Warranty, 3 yr
Housing Depth:
22 5/8 in
Housing Length:
27 7/8 in
For Minimum Beam Flange Width:
Not Applicable
For Maximum Beam Flange Width:
Not Applicable
For Maximum Beam Height:
Not Applicable
MFR Warranty Length:
1 yr
Body Width:
11 11/16 in
Body Depth:
22 5/8 in
For Minimum Beam Height:
Not Applicable
Body Length:
27 7/8 in
Minimum Radius Curve:
Not Applicable
Maximum Lifting Length:
10 ft
Controller Cord Length:
6 ft
Trolley Wheel Diameter:
Not Applicable
Lifting Hook Opening Width:
22 5/8 in
Minimum Retracted Length:
22 19/32 in
Load Capacity:
4,000 lb
Minimum Between Hooks:
22 5/8 in
Motor HP:
2.4 hp
Phase:
3
Standards:
ASME B30.16, ASME HST-1M, FDA Approved, RoHS Compliant
Voltage:
230/460V
Fits Brand:
Harrington Hoists Inc
Lubrication:
Food Grade Oil
Reeving:
1
Thermal Protection:
Yes
Control Cord:
6 ft
Amps @ Low Volts:
2.4 A
Number of Speeds:
1
Trolley Configuration:
Hook Mounted
Trolley Speed:
Not Applicable
Lifting Hook Material:
Carbon Steel
Includes Clutch:
Clutch Included
Overload Protection Included:
Yes
Brake Type:
DC Current
Maximum Lift Speed:
Not Applicable
Included Components:
Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook
Fixed Lift Speed:
14 fpm
Clutch Type:
Friction
Minimum Lift Speed:
Not Applicable
Pendant IP Rating:
IP65
Chain Finish:
Epoxy Painted
Controls:
Push Button Pendant=Mount Type=Hook Mounted-No Trolley
Starts and Stops per Hour:
360
Duty Classification:
H4
Maximum Pulling Capacity:
Not Applicable
Number of Reeves:
1
Motor Horsepower:
2 3/8 hp
Headroom:
22 5/8 in
Includes Brake:
Brake Included
Lifting Hook Type:
Swivel Hook with Safety Latch
Maximum Lifting Capacity:
4,000 lb
Current at Minimum Voltage:
2.4 A
Trolley Wheel Material:
Not Applicable
Current at Maximum Voltage:
2.4 A
Body Finish:
Epoxy Painted
Number of Load Chains:
1
Trolley IP Rating:
Not Applicable
Programmable:
Non-Programmable
