NER-FG Food Grade Electric Chain Hoist 15' Lift-Capacity 1 Tons NER010L-FG Electric Chain Trolley HARRINGTON

Product Overview

The NER010L-FG-15 HARRINGTON NER-FG Food Grade Electric Chain Hoist is a game-changer in the food processing and packaging industry. With a lift capacity 1 Tons and a 15' lift capacity, this electric chain hoist is designed to meet all your lifting needs with utmost precision and efficiency.One of the standout features of this electric chain hoist is its durable construction and use of food-grade materials. The hoist is built to withstand the rigorous demands of the food industry while ensuring impeccable hygiene standards. This ensures that your production line remains compliant with food industry regulations and maintains the highest quality standards.Operating the NER010L-FG-15 is a breeze. Its user-friendly design allows for easy handling and smooth lifting operation. You can count on its reliable performance to streamline your operations and enhance productivity in your food-related industry.Safety is a top priority when it comes to lifting equipment, and this electric chain hoist leaves no room for compromise. Equipped with advanced safety features, such as overload protection and emergency stop functions, the NER010L-FG-15 ensures that your personnel and products are always secure during lifting operations.Whether you're lifting heavy loads or delicate products, the NER010L-FG-15 provides the precision and control you need. Its smooth lifting motion guarantees that your products will be handled with care and precision, reducing the risk of damage and improving the overall quality of your operations.Upgrade your production line today with the NER010L-FG-15 HARRINGTON NER-FG Food Grade Electric Chain Hoist. With its exceptional performance, reliability, and compliance with food industry regulations, this hoist is an essential tool for any food-related industry. Invest in the best and witness a significant improvement in safety, productivity, and overall efficiency.

Product Specifications

.

Part Number:

NER010L-FG-15

Color:

White

Hoist Lift:

15 ft

Product:

Electric Food Grade Chain Hoist, 2,000 lb, 15 ft, Hook Mounted-No Trolley, White=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Quick Disconnect Plugs On Pendant and Power Cord

Lift Speed:

14 fpm

Housing Width:

9 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

17 in

Housing Length:

24 1/8 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

9 11/16 in

Body Depth:

17 in

For Minimum Beam Height:

Not Applicable

Body Length:

24 1/8 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

17 in

Minimum Retracted Length:

16 29/32 in

Load Capacity:

2,000 lb

Minimum Between Hooks:

17 in

Motor HP:

1.2 hp

Phase:

3

Standards:

ASME B30.16, ASME HST-1M, FDA Approved, RoHS Compliant

Voltage:

230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Food Grade Oil

Reeving:

1

Thermal Protection:

Yes

Control Cord:

11 ft

Amps @ Low Volts:

4.8 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted-No Trolley

Trolley Speed:

Not Applicable

Material:

Not Applicable

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

14 fpm

Clutch Type:

Friction

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Epoxy Painted

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

17 in

Includes Brake:

Brake Included

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

2,000 lb

Current at Minimum Voltage:

4.8 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

4.8 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
