NER-FG Food Grade Electric Chain Hoist 10' Lift-Capacity 1 Tons NER010L-FG Electric Chain Trolley HARRINGTON

Product Overview

The NER010L-FG-10 HARRINGTON NER-FG Food Grade Electric Chain Hoist is a state-of-the-art lifting solution designed specifically for the food industry. With a 10' lift and Capacity 1 Tons, this electric chain hoist is perfect for food processing and packaging applications. Whether you need to lift ingredients, equipment, or finished products, this hoist delivers precision and efficiency every time.One of the standout features of the NER010L-FG-10 HARRINGTON NER-FG Food Grade Electric Chain Hoist is its food-grade construction. Engineered with the highest standards of cleanliness and hygiene in mind, this hoist ensures that your products remain uncontaminated during the lifting process. Its carefully designed construction prevents any food particles or debris from becoming trapped, making it easy to clean and maintain.In addition to its food-grade design, this electric chain hoist is built to withstand the demanding conditions of the food industry. With its durable and reliable build, it can handle rigorous lifting tasks without compromising its performance. This hoist provides smooth and seamless operations, allowing you to lift and transport your products with ease.Trust in the NER010L-FG-10 HARRINGTON NER-FG Food Grade Electric Chain Hoist for all your food-grade lifting needs. Whether you're operating in a small food processing facility or a large-scale packaging plant, this hoist is the perfect solution for you. Its dependable performance and exceptional durability will ensure that your lifting operations run smoothly, reducing downtime and increasing productivity.Invest in the NER010L-FG-10 HARRINGTON NER-FG Food Grade Electric Chain Hoist today and experience the difference it can make in your food processing and packaging operations. With its high standards of cleanliness, reliability, and efficiency, this hoist is the ultimate tool for lifting and moving food-grade products.

Product Specifications

.

Part Number:

NER010L-FG-10

Color:

White

Hoist Lift:

10 ft

Product:

Electric Food Grade Chain Hoist, 2,000 lb, 10 ft, Hook Mounted-No Trolley, White=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Quick Disconnect Plugs On Pendant and Power Cord

Lift Speed:

14 fpm

Housing Width:

9 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

17 in

Housing Length:

24 1/8 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

9 11/16 in

Body Depth:

17 in

For Minimum Beam Height:

Not Applicable

Body Length:

24 1/8 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

17 in

Minimum Retracted Length:

16 29/32 in

Load Capacity:

2,000 lb

Minimum Between Hooks:

17 in

Motor HP:

1.2 hp

Phase:

3

Standards:

ASME B30.16, ASME HST-1M, FDA Approved, RoHS Compliant

Voltage:

230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Food Grade Oil

Reeving:

1

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

4.8 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted-No Trolley

Trolley Speed:

Not Applicable

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

14 fpm

Clutch Type:

Friction

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Epoxy Painted

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

17 in

Includes Brake:

Brake Included

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

2,000 lb

Current at Minimum Voltage:

4.8 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

4.8 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
