NER Electric Chain Hoist 20' Lift-Capacity 1/2 Tons NER005S Electric Chain Hoist HARRINGTON

Product Overview

The NER005S-20 HARRINGTON NER Electric Chain Hoist is an exceptional product that delivers unrivaled performance and reliability. With its impressive lift capacity ranging from 1/8 to 20 tons, this electric hoist is built to handle even the toughest jobs. No matter the size or weight of the load, this hoist will tackle it with ease, making it the perfect tool for warehouses, construction sites, and industrial facilities.One of the standout features of the NER005S-20 HARRINGTON NER Electric Chain Hoist is its durable construction. Built to withstand rigorous use in harsh conditions, this hoist is designed for longevity. You can trust that it will provide consistent and reliable performance day after day, allowing you to focus on your work without any interruptions.In addition to its durability, this electric hoist also offers exceptional flexibility. With a lift height of 20 feet, it allows you to easily maneuver loads and reach almost any desired height. This versatility makes it perfect for a wide range of applications, whether you're lifting heavy machinery, equipment, or materials.When it comes to power and reliability, the NER005S-20 HARRINGTON NER Electric Chain Hoist exceeds expectations. It is specifically designed to meet the demands of heavy lifting operations, ensuring that you can complete your tasks efficiently and safely. This hoist offers the peace of mind you need when working with heavy loads, as it is built to handle even the most demanding lifting requirements.Overall, the NER005S-20 HARRINGTON NER Electric Chain Hoist is an exceptional product that delivers outstanding performance and reliability. If you're looking for a powerful and durable hoist that can handle heavy loads with ease, look no further. Trust in the NER005S-20 HARRINGTON NER Electric Chain Hoist to exceed your expectations and provide you with the power and reliability you need for your lifting operations.

Product Specifications

.

Part Number:

NER005S-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Electric Chain Hoist, 1,000 lb, 20 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Limit Switches, Plug-In Connections

Lift Speed:

29 fpm

Housing Width:

13 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

7 1/2 in

Housing Length:

20 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 11/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

Not Applicable

Body Length:

20 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

20 ft

Controller Cord Length:

8 3/16 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

14 19/32 in

Load Capacity:

1,000 lb

Minimum Between Hooks:

14 5/8 in

Motor HP:

1.2 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Brake:

DC Current

Control Cord:

16 ft

Amps @ Low Volts:

4.8 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted-No Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Dual Speed VFD, Easy Access Suspension, Extreme Duty Motor, Secondary Brake, Smart Brake Technology, State-Of-The-Art Chain Technology, Unique Smart Limit Option

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

29 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

14 19/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

4.8 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

2.5 A

Body Finish:

Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
