ERP Electric Chain Hoist with Push Trolley 15' Lift-Capacity 1/4 Tons ERP003H Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The ERP003H-15 HARRINGTON ERP Electric Chain Hoist with Push Trolley is a reliable and versatile solution for transporting heavy loads efficiently and effortlessly. With a capacity ranging from 1/4 Tons, this electric chain hoist is suitable for small workshops and occasional moves.Equipped with a PT push trolley, moving your loads across your workspace becomes a breeze. The sturdy construction of the hoist ensures durability and safety, providing peace of mind during operation. With a lift height of 15', this hoist offers ample reach for a wide range of applications.When it comes to productivity and efficiency, the ERP003H-15 HARRINGTON ERP Electric Chain Hoist with Push Trolley excels. Its versatile design allows you to complete various tasks, from small projects to heavy-duty tasks, with ease and precision. No matter the load, this hoist can handle it effortlessly.Investing in the ERP003H-15 HARRINGTON ERP Electric Chain Hoist with Push Trolley is a smart choice for workshops and construction sites. Its exceptional performance and rugged construction ensure years of reliable service. Say goodbye to the manual lifting hassle and let this hoist do the heavy lifting for you.If you're in need of an efficient and durable solution for transporting heavy loads, the ERP003H-15 HARRINGTON ERP Electric Chain Hoist with Push Trolley is the perfect choice. It will revolutionize your work by enhancing productivity and efficiency. Don't miss out on the opportunity to simplify your workload-get the ERP003H-15 HARRINGTON ERP Electric Chain Hoist with Push Trolley today!

Product Specifications

.

Part Number:

NERP003H-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 500 lb, 10 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

53 fpm

Housing Width:

13 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

7 1/2 in

Housing Length:

20 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 11/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

3 in

Body Length:

20 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

3 1/5 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

16 5/16 in

Load Capacity:

500 lb

Minimum Between Hooks:

16 5/16 in

Motor HP:

1.2 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

11 ft

Amps @ Low Volts:

4.8 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

53 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

16 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

4.8 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

2.5 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
