EQP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 1 Ton EQP010SD Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The EQP010SD-10 HARRINGTON EQP Electric Chain Hoist with Push Trolley is the ultimate lifting solution for industrial environments. This electric chain hoist is designed to provide reliable performance and efficient load transportation, making it an essential tool for any lifting task.With a lift capacity of 10', the EQP010SD-10 offers a wide range of options to suit your specific needs. Whether you need to lift light loads of 1/8 ton or heavy loads of 1 ton, this hoist is built to handle it all. You can trust this hoist to deliver superior lifting capabilities without compromising safety.One of the standout features of the EQP010SD-10 is its VFD control, which allows for precise speed adjustments. This means you can easily control the hoist's speed to match the requirements of your lifting task, ensuring smooth and efficient operation. Whether you need a slow and steady lift or a quick and precise movement, this hoist has got you covered.The EQP010SD-10 also comes equipped with a PT push trolley, adding even more convenience to your lifting tasks. The push trolley enables effortless movement of your load, making it easier than ever to transport heavy items with ease. Say goodbye to struggling with heavy loads and wasting time trying to maneuver them into position. With the push trolley, transporting your load becomes a breeze.Upgrade your lifting solutions with the EQP010SD-10 HARRINGTON EQP Electric Chain Hoist with Push Trolley. This hoist is built to meet the demands of industrial settings with its power, durability, and efficiency. Trust in Harrington's reputation for quality and reliability, and experience superior lifting capabilities like never before.

Product Specifications

.

Part Number:

EQP010SD-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 2,000 lb, 10 ft, Push Trolley, Yellow=Hoist Mount=Push Trolley

Includes:

Chain Container

Lift Speed:

23/3.8 fpm

Housing Width:

15 29/32 in

Manufacturers Warranty Length:

3 yr

Housing Depth:

9 39/64 in

Housing Length:

16 19/64 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

5 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

3 yr

Body Width:

15 29/32 in

Body Depth:

9 5/8 in

For Minimum Beam Height:

3 9/16 in

Body Length:

16 5/16 in

Minimum Radius Curve:

51 1/4 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

4 1/4 in

Lifting Hook Opening Width:

1 3/16 in

Minimum Retracted Length:

19 5/16 in

Load Capacity:

2,000 lb

Minimum Between Hooks:

19 5/16 in

Motor HP:

2 hp

Phase:

3

Standards:

ASME HST-4, C22.2 No.33/14-13/66, CSA, UL 508A

Voltage:

460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

5.5 A

Number of Speeds:

2

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

No-Load High Speed, Self-Adjusting Maintenance-Free Brake, Stamped Steel Side Plates, Unique Chain Guide, Variable Frequency Drive (VFD)

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

23 fpm

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

Not Applicable

Clutch Type:

Friction

Minimum Lift Speed:

3.8 fpm

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

120, 240

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

2 hp

Headroom:

19 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

2,000 lb

Current at Minimum Voltage:

10.5 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

5.5 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Programmable by Internal Controls
