EQP Electric Chain Hoist with Push Trolley 15' Lift-Capacity 1/4 Ton EQP003SD Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The EQP003SD-15 HARRINGTON EQP Electric Chain Hoist with Push Trolley 15' Lift is the ultimate solution for all your lifting needs. Whether you're working in a warehouse, construction site, or any other industrial setting, this electric chain hoist is guaranteed to meet and exceed your expectations.Equipped with dual-speed VFD control, the EQP003SD-15 ensures precise and efficient lifting operations. You'll have full control over the speed, allowing you to safely and smoothly move your load with ease. No more struggling with heavy loads or worrying about accidents. This hoist is designed to make your job easier and more productive.The PT push trolley that comes with the EQP003SD-15 adds even more versatility and convenience to this already remarkable hoist. With the push trolley, you can easily transport your load from one location to another without the need for additional equipment or manpower. It's a cost-effective solution that will save you time and effort.With Capacity ranging from 1/8 to 1 ton, this hoist can handle a wide range of weights. Whether you're lifting lightweight objects or heavy machinery, the EQP003SD-15 has got you covered. Its durable construction ensures long-lasting performance, meaning you can rely on this hoist to get the job done day in and day out.The 15' lift height provides ample vertical reach, allowing you to lift your load to great heights. No matter how high you need to go, this hoist will deliver. Plus, with Harrington's reputation for superior quality and reliability, you can trust that this hoist will perform exceptionally well even in the most demanding environments.In conclusion, if you're looking for a reliable and efficient electric chain hoist with a push trolley, look no further than the EQP003SD-15 HARRINGTON EQP Electric Chain Hoist with Push Trolley 15' Lift. This hoist is built to last and will make your lifting operations easier and more productive. Don't settle for anything less than the best. Choose Harrington.

Product Specifications

.

Part Number:

EQP003SD-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 500 lb., 15 ft, Push Trolley, Yellow=Hoist Mount=Push Trolley

Includes:

Chain Container

Lift Speed:

33/5.5 fpm

Housing Width:

14 13/32 in

Manufacturers Warranty Length:

3 yr

Housing Depth:

9 7/64 in

Housing Length:

16 19/64 in

For Minimum Beam Flange Width:

2 1/2 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

3 yr

Body Width:

14 13/32 in

Body Depth:

9 1/8 in

For Minimum Beam Height:

3 in

Body Length:

16 5/16 in

Minimum Radius Curve:

43 1/4 in

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

3 1/4 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

16 5/16 in

Load Capacity:

500 lb.

Minimum Between Hooks:

16 5/16 in

Motor HP:

0.67 hp

Phase:

3

Standards:

ASME HST-4, C22.2 No.33/14-13/66, CSA, UL 508A

Voltage:

460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

11 ft

Amps @ Low Volts:

2.9 A

Number of Speeds:

2

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

No-Load High Speed, Self-Adjusting Maintenance-Free Brake, Stamped Steel Side Plates, Unique Chain Guide, Variable Frequency Drive (VFD)

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

33 fpm

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

Not Applicable

Clutch Type:

Friction

Minimum Lift Speed:

5.5 fpm

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Programmable by Internal Controls=Mount Type=Push Trolley

Starts and Stops per Hour:

120, 240

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

5/8 hp

Headroom:

16 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

5.1 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

2.8 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Programmable by Internal Controls
