EQG Electric Chain Hoist with Geared Trolley 10' Lift-Capacity 1/4 EQG003SD Electric Chain Hoist with Geared Trolley HARRINGTON

Product Overview

The EQG003SD-10 HARRINGTON EQG Electric Chain Hoist with Geared Trolley 10' Lift is a powerhouse of productivity. Whether you are working in a medium-or heavy-duty industrial setting, this electric chain hoist is designed to enhance efficiency and ensure smooth material movement.Equipped with a three-phase dual speed motor, this hoist offers precise control and optimal performance. No matter the load, you can transport it with ease and accuracy using the included GT geared trolley. This trolley allows for precise movements, ensuring that every load is placed exactly where it needs to be.Not only does this electric chain hoist provide exceptional performance, it is also built to last. Its robust construction guarantees durability and longevity, making it a reliable investment for any industrial operation.The EQG003SD-10 HARRINGTON EQG Electric Chain Hoist with Geared Trolley 10' Lift offers a capacity range from 1/4 ton, making it suitable for a wide range of applications. Whether you need to lift heavy machinery, transport materials, or perform intricate operations, this hoist can handle the task with ease.With its versatile capabilities and reliable performance, the EQG003SD-10 HARRINGTON EQG Electric Chain Hoist with Geared Trolley 10' Lift is the ideal choice for any industrial setting. It offers efficiency, precision, and reliability, allowing you to enhance productivity and streamline operations. Invest in this electric chain hoist and experience the difference it can make in your workflow.Make your work easier and more efficient with the EQG003SD-10 HARRINGTON EQG Electric Chain Hoist with Geared Trolley 10' Lift. This hoist is built to withstand the demands of rigorous industrial environments and provide reliable performance day after day. Its powerful motor and geared trolley ensure smooth and accurate movements, allowing for precise positioning of loads. Plus, with its wide range of Capacity, this hoist can handle a variety of tasks, making it a versatile tool for any industrial operation. Invest in the EQG003SD-10 HARRINGTON EQG Electric Chain Hoist with Geared Trolley 10' Lift and experience enhanced productivity and efficiency in your workplace. Trust Harrington, a brand known for its quality and reliability, to provide you with a hoist that will meet and exceed your expectations.

Product Specifications

.

Part Number:

EQG003SD-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 500 lb., 10 ft, Geared Trolley, Yellow=Hoist Mount=Geared Trolley

Includes:

Chain Container

Lift Speed:

33/5.5 fpm

Housing Width:

14 13/32 in

Manufacturers Warranty Length:

3 yr

Housing Depth:

9 7/64 in

Housing Length:

16 45/64 in

For Minimum Beam Flange Width:

2 9/32 in

For Maximum Beam Flange Width:

5 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

3 yr

Body Width:

14 13/32 in

Body Depth:

9 1/8 in

For Minimum Beam Height:

3 in

Body Length:

16 23/32 in

Minimum Radius Curve:

51 3/16 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

4 1/4 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

16 11/16 in

Load Capacity:

500 lb.

Minimum Between Hooks:

16 7/16 in

Motor HP:

0.67 hp

Phase:

3

Standards:

ASME HST-4, C22.2 No.33/14-13/66, CSA, UL 508A

Voltage:

460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Brake:

Pull Rotor

Control Cord:

6 ft

Amps @ Low Volts:

2.9 A

Number of Speeds:

2

Trolley Configuration:

Geared Trolley

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, Manually Operated Trolley, No-Load High Speed, Unique Chain Guide, Variable Frequency Drive (VFD)

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

33 fpm

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

Not Applicable

Clutch Type:

Friction

Minimum Lift Speed:

5.5 fpm

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Geared Trolley

Starts and Stops per Hour:

120, 240

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

5/8 hp

Headroom:

16 13/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

5.1 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

2.8 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Programmable by Internal Controls
