EQ Electric Chain Hoist 10' Lift-Capacity 1/4 Ton EQ003SD Electric Chain Hoist HARRINGTON

Product Overview

Upgrade your industrial and workstation applications with the EQ003SD-10 HARRINGTON EQ Electric Chain Hoist. Designed for medium to heavy-duty tasks, this electric chain hoist is the ultimate solution for all your lifting needs. With its dual-speed VFD and 3-phase motor, this hoist guarantees smooth and precise lifting operations every time.Featuring a 10' lift height and Capacity ranging from 1/4 ton, the EQ003SD-10 offers versatility and efficiency in any project. Whether you are working in a factory, construction site, or warehouse, this hoist has the power and capability to handle the toughest jobs with ease.The EQ003SD-10 is packed with advanced features that ensure optimal power and speed control, providing you with the control and accuracy you need to get the job done right. Say goodbye to manual labor and hello to increased productivity with this industry-leading electric chain hoist.Harrington is a trusted brand known for its high-quality and reliable performance, and the EQ003SD-10 is no exception. Built to withstand the most demanding environments, this hoist is made to last. With its durable construction and solid design, you can rely on this hoist to deliver consistent and dependable performance day after day.Streamline your operations and enhance your productivity with the EQ003SD-10 HARRINGTON EQ Electric Chain Hoist. Whether you need to lift heavy loads or move materials with precision, this hoist is your go-to solution. Experience the power, efficiency, and reliability of an industry-leading electric chain hoist with the EQ003SD-10 from Harrington.

Product Specifications

.

Part Number:

EQ003SD-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 500 lb., 10 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container

Lift Speed:

33/5.5 fpm

Housing Width:

14 13/32 in

Manufacturers Warranty Length:

3 yr

Housing Depth:

9 7/64 in

Housing Length:

17 19/64 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

3 yr

Body Width:

14 13/32 in

Body Depth:

9 1/8 in

For Minimum Beam Height:

15 in

Body Length:

17 5/16 in

Minimum Radius Curve:

10 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

17 5/16 in

Load Capacity:

500 lb.

Minimum Between Hooks:

17 5/16 in

Motor HP:

0.67 hp

Phase:

3

Standards:

ASME HST-4, C22.2 No.33/14-13/66, CSA, UL 508A

Voltage:

460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

2.9 A

Number of Speeds:

2

Trolley Configuration:

Hook/Suspension Bar Mounted

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, No-Load High Speed, Self-Adjusting Maintenance-Free Brake, Unique Chain Guide, Variable Frequency Drive (VFD)

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

33 fpm

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

Not Applicable

Clutch Type:

Friction

Minimum Lift Speed:

5.5 fpm

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Programmable by Internal Controls=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

120, 240

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

5/8 hp

Headroom:

17 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

5.1 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

2.8 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Programmable by Internal Controls
