EMP Electric Chain Hoist with Push Trolley 15' Lift-Capacity 1000 Lbs EMP005C Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The EMP005C-15 HARRINGTON EMP Electric Chain Hoist with Push Trolley is a powerful and reliable tool designed to make material handling a breeze. This versatile hoist is equipped with a 15' lift capacity, perfect for various workstations and occasional material moves.With the EM series mini electric chain hoist and PT push trolley, you can experience smooth and effortless lifting. The compact design of this hoist allows for easy installation and operation, making it ideal for businesses that require efficient material handling.This electric chain hoist is built to handle Capacity ranging from 1000 lbs, ensuring that it can handle a wide range of loads. Whether you need to lift heavy machinery or transport materials in your workshop, the EMP005C-15 HARRINGTON EMP Electric Chain Hoist with Push Trolley is up to the task.Safety is a top priority, and this hoist is designed with that in mind. It is equipped with various safety features such as a electromagnetic brake system that provides instant stopping power, preventing accidents and ensuring the security of your load.The EMP005C-15 HARRINGTON EMP Electric Chain Hoist with Push Trolley also offers exceptional durability and longevity. It is constructed with high-quality materials that can withstand the rigors of daily use, ensuring that it will be a reliable tool for years to come.With this electric chain hoist, you can get the job done quickly and efficiently. Its powerful motor and smooth operation allow for fast material handling, improving productivity in your workplace.In conclusion, the EMP005C-15 HARRINGTON EMP Electric Chain Hoist with Push Trolley is a powerful and reliable solution for all your lifting needs. Its versatility, safety features, and durability make it an essential tool in any business that requires easy and efficient material handling. Invest in this hoist today and experience the difference it can make in your workplace.

Product Specifications

.

Part Number:

EMP005C-15

Color:

Yellow

Hoist Lift:

3

Product:

Electric Hoists=Hoist Mount=1

Includes:

1.4 A

For Minimum Beam Flange Width:

2 9/32 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

5 yr

Body Width:

11 1/2 in

Body Depth:

9 13/32 in

For Minimum Beam Height:

3 1/2 in

Body Length:

11 1/2 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

15 ft

Controller Cord Length:

8 3/16 ft

Lifting Hook Opening Width:

29/32 in

Minimum Retracted Length:

14 5/16 in

Phase:

3

Number of Speeds:

1

Features:

Fits Tapered or Flat-Flanged Beams, Upper Limit Switch, Non-Drip, Grease Packed Gear Box, Solid State Relay Board, Unique Chain Guide

Lifting Hook Material:

Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Electromagnetic

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Rubber Bumpers

Fixed Lift Speed:

8 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

300

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

2

Motor Horsepower:

3/8 hp

Headroom:

14 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP65

Lifting Hook Type:

Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

1.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

1.4 A

Number of Load Chains:

1

Body Material:

Die-Cast Aluminum

Programmable:

Non-Programmable
