EMP Electric Chain Hoist with Push Trolley 20' Lift-Capacity 250 Lbs EMP001S Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The EMP001S-20 HARRINGTON EMP Electric Chain Hoist with Push Trolley is the ultimate solution for all your material handling needs. This high-quality mini electric chain hoist, combined with the reliable PT push trolley, provides seamless movement of materials in workstations and during occasional moves.Featuring a generous 20' lift and Capacity ranging from 250 lbs, this versatile hoist ensures smooth and efficient operations. Whether you need to lift heavy equipment or transport materials across different areas, this hoist-trolley combo is up for the job.Gone are the days of manual labor and straining yourself to move heavy objects. With the EMP001S-20 HARRINGTON EMP Electric Chain Hoist with Push Trolley, you can say goodbye to all that hassle and elevate your productivity. This durable and compact hoist-trolley combo is designed to make your work easier.Not only is this product extremely efficient and reliable, but it is also easy to use. The electric chain hoist is equipped with user-friendly controls, allowing you to effortlessly maneuver materials without any complications or delays. The push trolley adds even more convenience, providing smooth movement along beams and tracks.When it comes to safety, HARRINGTON has got you covered. The EMP001S-20 HARRINGTON EMP Electric Chain Hoist with Push Trolley complies with all the necessary safety regulations and features built-in safety mechanisms. You can have peace of mind knowing that your equipment and materials are in good hands.Invest in the EMP001S-20 HARRINGTON EMP Electric Chain Hoist with Push Trolley today and experience the convenience and reliability that HARRINGTON brings to your workplace. Don't miss out on this opportunity to streamline your material handling processes and enhance your productivity. Shop now and make your work easier and more efficient with this top-of-the-line hoist-trolley combo.

Product Specifications

.

Part Number:

EMP001S-20

Color:

Yellow

Hoist Lift:

3

Product:

Electric Hoists=Hoist Mount=1

Includes:

Friction Clutch

Lift Speed:

29/32 in

For Minimum Beam Flange Width:

2 9/32 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

5 yr

Body Width:

11 1/2 in

Body Depth:

7 29/32 in

For Minimum Beam Height:

3 1/2 in

Body Length:

11 1/2 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

20 ft

Controller Cord Length:

8 3/16 ft

Lifting Hook Opening Width:

29/32 in

Minimum Retracted Length:

12 3/16 in

Phase:

3

Brake:

Electromagnetic

Finish:

Nickel Plated

Number of Speeds:

1

Features:

Fits Tapered or Flat-Flanged Beams, Upper Limit Switch, Non-Drip, Grease Packed Gear Box, Solid State Relay Board, Unique Chain Guide

Material:

Steel

Lifting Hook Material:

Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Electromagnetic

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Rubber Bumpers

Fixed Lift Speed:

32 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

300

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/8 hp

Headroom:

12 3/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP65

Lifting Hook Type:

Hook with Safety Latch

Maximum Lifting Capacity:

250 lb

Current at Minimum Voltage:

1.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

1.4 A

Number of Load Chains:

1

Body Material:

Die-Cast Aluminum

Programmable:

Non-Programmable
