EM Electric Hoist 20' Lift-Capacity 1000 Lbs EM005C Electric Hoist HARRINGTON

Product Overview

The EM005C-20 HARRINGTON EM Electric Hoist is engineered to elevate your lifting operations with unmatched efficiency and reliability. Designed specifically for heavy-duty tasks, this electric hoist delivers exceptional performance with a maximum lift capacity of 1000 lbs.

Crafted for versatility, the EM Electric Hoist features advanced Solid State Relay (SSR) technology and a microcontroller (MCU) that ensure precise control during operation. Whether you’re lifting heavy machinery, moving bulk materials, or managing complex projects, this hoist is ideally equipped to meet your lifting needs with ease and convenience, reaching heights of up to 20 feet.

• High Load Capacity: Capable of lifting up to 1000 lbs, suitable for a variety of heavy-duty applications.
• Precision Control: Features Solid State Relay (SSR) technology and microcontroller (MCU) for reliable and exact lifting operations.
• Safety First: Incorporates advanced safety mechanisms such as overload protection and an emergency stop button.
• User-Friendly Interface: Designed with an intuitive control panel for simple operation and monitoring.
• Durable Construction: Built with high-quality materials to withstand extensive use and challenging working conditions.
• Robust Design: Engineered to handle demanding lifting tasks, ensuring longevity and dependable performance.

This electric hoist is your ultimate solution for rigorous lifting demands. Its robust features ensure that even under the highest stress levels, you can rely on its efficiency. Trust in the EM005C-20 for safe and efficient lifting operations in your industrial or commercial setting. Don't compromise on quality; invest in the HARRINGTON EM Electric Hoist today for enhanced productivity and performance that you can count on.

Product Specifications

.

Part Number:

EM005C-20

Color:

Yellow

Hoist Lift:

3

Product:

Electric Hoists=Hoist Mount=1

Includes:

3/8 hp

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

5 yr

Body Width:

11 1/2 in

Body Depth:

9 13/32 in

For Minimum Beam Height:

Not Applicable

Body Length:

11 1/2 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

20 ft

Controller Cord Length:

8 3/16 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 13/32 in

Minimum Retracted Length:

13 19/32 in

Phase:

3

Number of Speeds:

1

Features:

Upper Limit Switch, Non-Drip, Grease Packed Gear Box, Solid State Relay Board, Unique Chain Guide

Lifting Hook Material:

Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Electromagnetic

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant

Fixed Lift Speed:

8 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

300

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

2

Motor Horsepower:

3/8 hp

Headroom:

13 19/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP65

Lifting Hook Type:

Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

1.4 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

1.4 A

Number of Load Chains:

1

Body Material:

Die-Cast Aluminum

Programmable:

Non-Programmable
