SKU:
ED350DS-10
Condition:
New
Availability:
In stock
Weight:
34.00 LBS
Shipping:
Free Shipping
Part Number:
ED350DS-10
Color:
White and Orange
Hoist Lift:
10 ft
Product:
Electric Chain Hoist, 350 lb, 10 ft, Hook Mounted-No Trolley, White and Orange=Hoist Mount=Hook Mounted-No Trolley
Includes:
Safety Latch, Safety Standards
Lift Speed:
66/13 fpm
Housing Width:
5 13/16 in
Manufacturers Warranty Length:
1 yr
Housing Depth:
6 in
Housing Length:
16 29/32 in
For Minimum Beam Flange Width:
Not Applicable
For Maximum Beam Flange Width:
Not Applicable
For Maximum Beam Height:
Not Applicable
MFR Warranty Length:
1 yr
Body Width:
5 13/16 in
Body Depth:
6 in
For Minimum Beam Height:
Not Applicable
Body Length:
16 29/32 in
Minimum Radius Curve:
Not Applicable
Maximum Lifting Length:
10 ft
Controller Cord Length:
7 ft
Trolley Wheel Diameter:
Not Applicable
Lifting Hook Opening Width:
1 in
Minimum Retracted Length:
13 in
Load Capacity:
350 lb
Minimum Between Hooks:
13 in
Motor HP:
0.8 hp
Phase:
1
Standards:
Safety Latch, Safety Standards
Voltage:
120v
Fits Brand:
Harrington Hoists Inc
Lubrication:
Oil Bath
Reeving:
1
Thermal Protection:
No
Control Cord:
7 ft
Number of Speeds:
2
Trolley Configuration:
Hook Mounted-No Trolley
Trolley Speed:
Not Applicable
Features:
Heat-Treated Gearing, High Speed Motor, Integrated Friction Clutch, Standard Double-Braking System
Lifting Hook Material:
Carbon Steel
Includes Clutch:
Clutch Included
Overload Protection Included:
No
Brake Type:
Weston Style Load Brake
Maximum Lift Speed:
66 fpm
Included Components:
Chain Container, Pendant, Safety Latch Hook
Fixed Lift Speed:
Not Applicable
Clutch Type:
Friction Clutch
Minimum Lift Speed:
13 fpm
Pendant IP Rating:
IP65
Chain Finish:
Enamel
Controls:
Push Button Pendant=Mount Type=Hook Mounted-No Trolley
Starts and Stops per Hour:
180
Duty Classification:
H3
Maximum Pulling Capacity:
Not Applicable
Number of Reeves:
1
Motor Horsepower:
3/4 hp
Headroom:
13 in
Includes Brake:
Brake Included
Hoist IP Rating:
IP54
Lifting Hook Type:
Swivel Hook with Safety Latch
Maximum Lifting Capacity:
350 lb
Current at Minimum Voltage:
0.416666666666667
Trolley Wheel Material:
Not Applicable
Current at Maximum Voltage:
0.416666666666667
Body Finish:
Enamel
Number of Load Chains:
1
Body Material:
Aluminum
Trolley IP Rating:
Not Applicable
Programmable:
Programmable by Internal Controls
