HARRINGTON CF Hand Chain Hoist 20' Lift-Capacity 5 Ton CF050 Hand Chain Hoist

Product Overview

The CF050-20 HARRINGTON CF Hand Chain Hoist is the ultimate lifting solution for your industrial needs. With its impressive 20-foot lift capacity, this hoist is capable of handling heavy loads with ease. Whether you need to lift 5 tons, the CF050 Hand Chain Hoist has got you covered.One of the standout features of this hoist is its die-cast aluminum body. This construction ensures exceptional durability and longevity, making it a reliable choice for any lifting task. The high-strength, heat-treated main pinion shaft and load gear further enhance its strength and functionality, allowing you to lift heavy loads without any worries.In terms of operation, the CF050-20 Hoist offers a smooth and effortless experience. Equipped with pre-lubricated ball bearings and precision machined gears, this hoist ensures smooth lifting motion with minimal effort. Additionally, its Weston-style load brake adds an extra layer of safety and stability, giving you peace of mind during lifting operations.The versatility of the CF050-20 Hoist is another reason to choose this product. It is suitable for a wide range of lifting applications, making it an essential tool in industries such as manufacturing, construction, and warehousing. Whether you need to lift heavy equipment, machinery, or materials, this hoist will deliver uncompromising performance and reliability.Maintenance is also a breeze with the CF050-20 Hoist. Its rugged design and high-quality components require minimal upkeep, saving you time and money in the long run. With this hoist, you can focus on your work without worrying about frequent repairs or downtime.In conclusion, the CF050-20 HARRINGTON CF Hand Chain Hoist is the perfect choice for those who demand exceptional performance and durability. With its robust construction, smooth operation, and versatile lifting capabilities, this hoist is a must-have for any industrial setting. Invest in the CF050-20 Hoist, and experience the difference it can make in your lifting operations.

Product Specifications

.

Part Number:

CF050-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Manual Chain Hoist, 10000 lb., Lift 20 ft.=Hoist Mount=Hook Mounted-No Trolley

Housing Width:

13 1/2 in

Manufacturers Warranty Length:

2 yr

Housing Depth:

6 in

Housing Length:

24 3/8 in

For Minimum Beam Flange Width:

Not Applicable

For Minimum Beam Flange Height:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Height:

Not Applicable

Body Width:

13 1/2 in

Body Depth:

6 in

Body Material:

Die-Cast Aluminum

Maximum Lifting Length:

20 ft

Lifting Hook Opening Width:

1 13/16 in

Minimum Retracted Length:

24 13/32 in

Load Capacity:

10,000 lb

Minimum Between Hooks:

24 1/2 in

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-2M

Item:

Manual Chain Hoist

Brake:

Weston Style

Trolley Configuration:

Hook Mounted-No Trolley

Features:

Heat-Treated Main Pinion Shaft, Lightweight Die-Cast Aluminum Housing, Reliable Weston-Style Load Brake, Smooth Running Pre-Lubricated Bearings

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Not Included

Overload Protection Included:

No

Chain Grade:

Grade 100

Included Components:

Safety Latch Hooks

Chain Finish:

Nickel Plated

Controls:

=Mount Type=Hook Mounted-No Trolley

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

3

Headroom:

24 13/32 in

Includes Brake:

Brake Included

Lifting Hook Type:

Hook with Safety Latch

Maximum Lifting Capacity:

10,000 lb

Number of Load Chains:

1
