CF Hand Chain Hoist 15' Lift-Capacity 1 1/2 Tons CF015 Hand Chain Hoist HARRINGTON

Product Overview

Elevate your lifting experience with the CF015-15 HARRINGTON CF Hand Chain Hoist. This manual hoist is built to provide simplicity and exceptional performance for all your lifting needs. With Capacity ranging from 1 1/2 Tons , this hoist is capable of handling a wide range of lifting tasks.Crafted with a durable die-cast aluminum body, the CF015-15 HARRINGTON CF Hand Chain Hoist is designed to last. Its high-strength, heat-treated main pinion shaft and load gear ensure exceptional durability, making it perfect for heavy-duty applications.Lifting with this hoist is effortless, thanks to its pre-lubricated ball bearings and precision machined gears. You can expect smooth and easy lifting every time. The Weston-style load brake adds an extra layer of safety and control, giving you peace of mind while operating the hoist.One of the standout features of the CF015-15 HARRINGTON CF Hand Chain Hoist is its long service life and low maintenance. It is designed to withstand heavy use, making it perfect for industrial settings where reliability is crucial. Spend less time on maintenance and more time on getting the job done.Not only is this hoist high-performing, but it is also user-friendly. Its easy operation allows for quick and efficient lifting and lowering of loads. Whether you are an experienced operator or new to using manual hoists, the CF015-15 HARRINGTON CF Hand Chain Hoist is the perfect tool for the job.From lifting heavy machinery to handling equipment and materials, this hoist is designed to deliver exceptional performance, reliability, and ease of use. Elevate your lifting experience with the CF015-15 HARRINGTON CF Hand Chain Hoist.

Product Specifications

.

Part Number:

CF015-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Manual Chain Hoist, 3000 lb., Lift 15 ft.=Hoist Mount=Hook Mounted-No Trolley

Housing Width:

8 in

Manufacturers Warranty Length:

2 yr

Housing Depth:

6 in

Housing Length:

17 5/16 in

For Minimum Beam Flange Width:

Not Applicable

For Minimum Beam Flange Height:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Height:

Not Applicable

Body Width:

8 in

Body Depth:

6 in

Body Material:

Die-Cast Aluminum

Maximum Lifting Length:

15 ft

Lifting Hook Opening Width:

1 5/16 in

Minimum Retracted Length:

17 5/16 in

Load Capacity:

3,000 lb

Minimum Between Hooks:

17 1/4 in

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-2M

Item:

Manual Chain Hoist

Brake:

Weston Style

Trolley Configuration:

Hook Mounted-No Trolley

Features:

Heat-Treated Main Pinion Shaft, Lightweight Die-Cast Aluminum Housing, Reliable Weston-Style Load Brake, Smooth Running Pre-Lubricated Bearings

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Not Included

Overload Protection Included:

No

Chain Grade:

Grade 100

Included Components:

Safety Latch Hooks

Chain Finish:

Nickel Plated

Controls:

=Mount Type=Hook Mounted-No Trolley

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Headroom:

17 5/16 in

Includes Brake:

Brake Included

Lifting Hook Type:

Hook with Safety Latch

Maximum Lifting Capacity:

3,000 lb

Number of Load Chains:

1
