Product Overview
The CB005-20 HARRINGTON CB Hand Chain Hoist is an industrial lifting powerhouse that is built to withstand even the toughest applications. With its exceptional durability and unmatched performance, this hoist is designed to handle any challenge with ease.Constructed with heavy-duty materials and top-of-the-line internal components, the CB005-20 HARRINGTON hoist offers unparalleled reliability and longevity. You can trust this hoist to consistently deliver outstanding performance day in and day out.With a lift capacity ranging from 1/2 ton to an impressive 100 ton, this hoist is ready to take on the toughest tasks in your industrial operations. No matter how big the job, the CB005-20 HARRINGTON hoist is up for the challenge, making it an invaluable asset in your workspace.Not only is this hoist incredibly robust, but it is also designed for easy maintenance. Its user-friendly construction allows for effortless routine maintenance, ensuring optimal performance and extending the lifespan of your CB005-20 HARRINGTON hoist.Investing in this high-quality hoist is a decision that will undoubtedly elevate your industrial operations to new heights. Whether you need to lift heavy machinery, transport materials, or perform any other lifting task, the CB005-20 HARRINGTON hoist provides the strength, reliability, and durability you need to get the job done efficiently and safely.Experience the unmatched capabilities and performance of the CB005-20 HARRINGTON CB Hand Chain Hoist. With its rugged construction, easy maintenance, and a wide range of Capacity to choose from, this hoist is an investment that will pay off for years to come. Trust in its power, dependability, and longevity to take your industrial operations to the next level.Product Specifications
.Product Videos
Videos Hide Videos Show Videos
Custom Field
Part Number CB005-20
Color Yellow
Hoist Lift 20 ft
Product Manual Chain Hoist, 20 ft.Lift=Hoist Mount=Hook Mounted-No Trolley
Housing Width 6 1/4 in
Manufacturers Warranty Length 2 yr
Housing Depth 6 1/4 in
Housing Length 11 13/64 in
For Minimum Beam Flange Width Not Applicable
For Minimum Beam Flange Height Not Applicable
For Maximum Beam Flange Width Not Applicable
For Maximum Beam Flange Height Not Applicable
Body Width 6 5/16 in
Body Depth 6 3/16 in
Body Material Steel
Maximum Lifting Length 20 ft
Lifting Hook Opening Width 1 3/32 in
Minimum Retracted Length 11 3/16 in
Load Capacity 1,000 lb
Minimum Between Hooks 11 in
Standards ANSI/ASME B30.16, ANSI/ASME HST-2M
Item Manual Chain Hoist
Brake Weston Style
Trolley Configuration Hook Mounted-No Trolley
Features Bearing-Supported High-Strength Pinion, Double Pawl Springs, High Impact Steel Housing, Maintenance-Free Slip Clutch
Lifting Hook Material Carbon Steel
Includes Clutch Clutch Included
Overload Protection Included Yes
Chain Grade Grade 100
Included Components Safety Latch Hooks
Controls =Mount Type=Hook Mounted-No Trolley
Maximum Pulling Capacity Not Applicable
Number of Reeves 1
Headroom 11 3/16 in
Includes Brake Brake Included
Lifting Hook Type Hook with Safety Latch
Maximum Lifting Capacity 1,000 lb
Number of Load Chains 1
