CB Hand Chain Hoist 10' Lift-Capacity 1/2 Ton CB005 Hand Chain Hoist HARRINGTON

Product Overview

Upgrade your industrial equipment with the CB005-10 HARRINGTON CB Hand Chain Hoist. This heavy-duty hoist is designed to handle tough conditions, making it perfect for any workload. With easy maintenance and repairability, say goodbye to downtime and hello to unrivaled performance and reliability.The CB005-10 Hand Chain Hoist offers a lift capacity ranging from 1/2 tons, ensuring that no job is too big or too small. Its durable construction and reliable operation make it the ideal choice for industries such as construction, manufacturing, and logistics.The compact and ergonomic design allows for easy maneuverability and precise control, making your lifting tasks effortless. Whether you need to lift heavy machinery or transport materials, this hoist will be your trusted companion to get the job done efficiently and safely.The CB005-10 HARRINGTON CB Hand Chain Hoist is built to last. Constructed with high-quality materials, it can withstand heavy loads and endure harsh environments. This longevity means you won't have to worry about frequent replacement or costly repairs.Safety is a top priority, and the CB005-10 Hand Chain Hoist has got you covered. It is equipped with multiple safety features, including a reliable braking system and a load-bearing chain that can securely hold the weight being lifted. Rest assured that your employees and equipment will be protected during every operation.Investing in the CB005-10 HARRINGTON CB Hand Chain Hoist means investing in the pinnacle of quality, durability, and efficiency. This hoist will not only enhance your productivity but also reduce downtime and maintenance costs. Trust the CB005-10 to handle your most demanding lifting tasks with ease.In conclusion, the CB005-10 HARRINGTON CB Hand Chain Hoist is the reliable solution for all your industrial lifting needs. Upgrade your equipment today and experience the superior performance and durability that this hoist has to offer.

Product Specifications

.

Part Number:

CB005-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Manual Chain Hoist, 10 ft.Lift=Hoist Mount=Hook Mounted-No Trolley

Housing Width:

6 1/4 in

Manufacturers Warranty Length:

2 yr

Housing Depth:

6 1/4 in

Housing Length:

11 13/64 in

For Minimum Beam Flange Width:

Not Applicable

For Minimum Beam Flange Height:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Height:

Not Applicable

Body Width:

6 5/16 in

Body Depth:

6 3/16 in

Body Material:

Steel

Maximum Lifting Length:

10 ft

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

11 3/16 in

Load Capacity:

1,000 lb

Minimum Between Hooks:

11 in

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-2M

Item:

Manual Chain Hoist

Brake:

Weston Style

Trolley Configuration:

Hook Mounted-No Trolley

Features:

Bearing-Supported High-Strength Pinion, Double Pawl Springs, High Impact Steel Housing, Maintenance-Free Slip Clutch

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Chain Grade:

Grade 100

Included Components:

Safety Latch Hooks

Controls:

=Mount Type=Hook Mounted-No Trolley

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Headroom:

11 3/16 in

Includes Brake:

Brake Included

Lifting Hook Type:

Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Number of Load Chains:

1
