AH Mini Cat Air Hoist 10' Lift-Capacity 250 lb. AH250P Air Powered Hoist HARRINGTON

Product Overview

The AH250P-10 HARRINGTON AH Mini Cat Air Hoist is the ultimate solution for all your lifting needs. With its lift capacity ranging from 250 lb, this hoist can handle a wide variety of applications, making it perfect for on-site jobs, workstations, and assembly line tasks.One of the standout features of the AH250P-10 is its lightweight and compact design. This makes it incredibly easy to transport and maneuver, allowing you to take it wherever you need to go. Whether you need to lift heavy equipment or move materials in a tight space, this hoist is up to the challenge.Powered by compressed air, this hoist offers efficient and consistent operation. The air-powered functionality ensures that you can rely on it to consistently provide the lifting power you need without worrying about running out of battery or fuel. It's a hassle-free solution that maximizes your productivity and minimizes downtime.Durability is another key feature of the AH250P-10. Built to withstand the rigors of everyday use, this hoist is crafted from high-quality materials that are designed to last. You can trust that it will continue to perform reliably even in demanding work environments, giving you peace of mind.Ease of use is a priority with the AH250P-10. Its user-friendly features ensure a smooth and hassle-free operation, even for those who are new to using hoists. You'll appreciate the intuitive controls and ergonomic design that make lifting a breeze.Say goodbye to heavy lifting and hello to a more efficient and convenient way of getting the job done with the AH250P-10 HARRINGTON AH Mini Cat Air Hoist. Invest in this hoist today and experience the difference it can make in your productivity and efficiency.

Product Specifications

.

Part Number:

AH250P-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Air Chain Hoist, 250 lb. Cap., 10 ft. Lift=Hoist Mount=Hook Mounted-No Trolley

Lift Speed:

42 fpm

Housing Width:

4 in

Manufacturers Warranty Length:

1 yr

Housing Length:

9 11/16 in

For Minimum Beam Flange Width:

Not Applicable

For Minimum Beam Flange Height:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Height:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

3 1/2 in

Body Depth:

11 5/16 in

For Minimum Beam Height:

Not Applicable

Body Length:

9 11/16 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

10 ft

Lifting Hook Opening Width:

29/32 in

Minimum Retracted Length:

12 in

Load Capacity:

250 lb

Minimum Between Hooks:

12 in

Standards:

ANSI/ASME B30.17

Item:

Air Chain Hoist

Reeving:

1

Trolley Configuration:

Hook Mounted-No Trolley

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Not Included

Overload Protection Included:

Yes

Brake Type:

Disc

Chain Grade:

Grade 80

Included Components:

Chain Container

Fixed Lift Speed:

42 fpm

Chain Finish:

Nickel Plated

Controls:

Pendant=Mount Type=Hook Mounted-No Trolley

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Headroom:

12 in

Includes Brake:

Brake Included

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

250 lb

Body Finish:

Painted

Number of Load Chains:

1

Body Material:

Cast Aluminum

Programmable:

Non-Programmable
