Harrington AH Mini-Cat Series Air Hoist - 500 lbs - Cord - 10 ft Lift

Write a Review
$3,581.71
$2,663.90
(You save $917.81 )
SKU: AH500C-10
Condition: New
Availability: Subject to Availability
Weight: 15.00 LBS
Shipping: Calculated at Checkout
Part Number: AH500C-10
Color: Yellow
Hoist Lift: 10 ft
product: Air Chain Hoist, 500 lb. Cap., 10 ft. Lift, Hoist Mount: Hook Mounted-No Trolley
Lift Speed: 10 ft
Housing Width: 4 in
Manufacturers Warranty Length: 1 yr
Housing Length: 9 11/16 in
For Minimum Beam Flange Width: Not Applicable
For Minimum Beam Flange Height: Not Applicable
For Maximum Beam Flange Width: Not Applicable
For Maximum Beam Flange Height: Not Applicable
For Maximum Beam Height: Not Applicable
MFR Warranty Length: 1 yr
Body Width: 3 1/2 in
Body Depth: 9 11/16 in
For Minimum Beam Height: Not Applicable
Body Length: 9 11/16 in
Minimum Radius Curve: Not Applicable
Maximum Lifting Length: 10 ft
Lifting Hook Opening Width: 29/32 in
Minimum Retracted Length: 12 in
Load Capacity: 0 - 999 lbs
Minimum Between Hooks: 12 in
Standards: ANSI/ASME B30.17
Item: Air Chain Hoist
Reeving: 1
Trolley Configuration: Hook Mounted-No Trolley
Lifting Hook Material: Carbon Steel
Includes Clutch: Clutch Not Included
Overload Protection Included: Yes
Brake Type: Disc
Chain Grade: Grade 80
Included Components: Chain Container
Fixed Lift Speed: 32 fpm
Chain Finish: Nickel Plated
Controls: Pendant, Mount Type: Hook Mounted-No Trolley
Maximum Pulling Capacity: Not Applicable
Number of Reeves: 1
Headroom: 12 in
Includes Brake: Brake Included
Lifting Hook Type: Swivel Hook with Safety Latch
Maximum Lifting Capacity: 500 lb
Body Finish: Painted
Number of Load Chains: 1
Body Material: Cast Aluminum
Programmable: Non-Programmable
Capacity: 0 - 999 lbs
Suspension / Mounting: Hook
Control: Pendant
Lift: 10 ft
Adding to cart… The item has been added
Harrington AH Mini-Cat Series Air Hoist - 500 lbs - Cord - 10 ft Lift

Harrington AH Mini-Cat Series Air Hoist - 500 lbs - Cord - 10 ft Lift

$3,581.71
$2,663.90
(You save $917.81 )
The AH500C-10 HARRINGTON AH Mini Cat Air Hoist is a revolutionary lifting tool that will change the way you work. With its exceptional power and versatility, this hoist is perfect for any on-site job, workstation, or assembly line application. Designed with a lifting capacity ranging from 500 lb., this air-powered hoist guarantees maximum efficiency and performance, all in a lightweight and compact design.The AH500C-10 HARRINGTON AH Mini Cat Air Hoist features a small body design that allows for easy maneuverability, making it ideal for navigating tight spaces and reaching difficult-to-access areas. Whether you're working in a cramped workshop or a bustling assembly line, this hoist will never let you down.With its generous 10' lift, this air-powered hoist provides ample reach, ensuring that you can lift and transport heavy loads with ease. No matter the height or distance, this hoist is up for the task. Say goodbye to back-breaking manual lifting and let the AH500C-10 HARRINGTON AH Mini Cat Air Hoist do the heavy lifting for you.Durability and reliability are essential qualities of the AH500C-10 HARRINGTON AH Mini Cat Air Hoist. Crafted with high-quality materials and precision engineering, this hoist is built to withstand the rigors of regular use. You can trust that this hoist will perform consistently and reliably, ensuring smooth and safe operations every time.Upgrade your lifting capabilities today with the AH500C-10 HARRINGTON AH Mini Cat Air Hoist. Experience its exceptional power, remarkable versatility, and unmatched efficiency for yourself. Whether you're a professional contractor, a DIY enthusiast, or an assembly line worker, this hoist is the perfect companion for all your lifting needs. Don't settle for anything less than the best. Choose the AH500C-10 HARRINGTON AH Mini Cat Air Hoist and experience the difference. Refuse to compromise and elevate your lifting game to new heights today.
All products sold by Harrington Hoists, Inc. (HHI) are warranted to be free from defects in material and workmanship from the date of shipment, with coverage periods varying by product type - 1 year for electric and air powered hoists (excluding (N)ER2 and EQ/SEQ hoists), powered trolleys, powered Tiger Track jibs and gantries, crane components, below-the-hook devices, and spare/replacement parts; 2 years for manual hoists and trolleys and beam clamps; 3 years for (N)ER2 hoists, EQ/SEQ hoists, (T)EM/(T)SEM hoists, and RY hoists; 5 years for manual Tiger Track jibs and gantries and hoist motor brakes for EQ/SEQ, (T)EM/(T)SEM, and RY; and 10 years for the (N)ER2 brake and TNER hoist motor brake - provided the buyer notifies HHI in writing within sixty (60) days of discovering any alleged defect and the product has been used according to manufacturer recommendations without abuse, lack of maintenance, misuse, negligence, or unauthorized repairs or alterations. If HHI's inspection confirms a defect in material or workmanship within the applicable warranty period, HHI will, at its discretion, repair or replace the part or product free of charge (not including installation), with delivery made F.O.B. HHI's place of business for U.S. customers or FCA HHI's U.S. location for international customers under Incoterms 2010; no warranty claim will be honored without valid proof of purchase, the customer must obtain a Return Goods Authorization before shipping the product freight-prepaid along with an explanation of the complaint, repaired products remain covered for the rest of the original warranty period, replacement parts installed after the original warranty period carry only a one-year replacement warranty (not including installation) from installation, and if no defect is found or the defect falls outside the warranty's scope, the customer is responsible for return shipping costs. HHI disclaims all other express or implied warranties, including merchantability or fitness for a particular purpose, and will not be liable for death, personal injury, property damage, or incidental, contingent, special, or consequential damages, losses, or expenses arising from the use or misuse of its products, regardless of whether such damage results from any act or failure to act by HHI, whether negligent, willful, or otherwise.
