Tractel Topal F10 0-100 Pipe Hook – 22,000 lbs Capacity

The Topal F10 0-100 Pipe Hook is a heavy-duty hook made for the lifting of pipes and cylindrical materials in various industrial environments. Designed with a working load limit of 22,000 lbs (10,000 kg) and a maximum opening of 4 inches (100 mm), this pipe hook delivers exceptional performance for lifting, positioning, and handling large loads safely and efficiently.

Built from high-grade alloy steel, the F10 0-100 combines durability with precise functionality. Hooks construction provides superior resistance to wear and deformation, giving users long-term reliability even under continuous use. Designed to work in pairs, these hooks offer secure and balanced lifting for a variety of pipe materials. This includes steel, concrete, and coated surfaces.

The 5/8-inch chain compatibility gives users strong, flexible rigging setups, and the smooth, contoured hook profile gives a firm grip that minimizes marking or surface damage. This makes the F10 perfect for jobs that require both heavy lifting capacity and careful material handling.

Specifications:

• Model: F10 0-100
• Working Load Limit (WLL): 22,000 lbs (10,000 kg)
• Maximum Opening: 4 in. (100 mm)
• Chain Size Compatibility: 5/8 in. (16.3 mm)
• Material: High-strength alloy steel
• Surface Finish: Corrosion-resistant coating for extended service life
• Design Use: In pairs for balanced and secure lifting
• Contact Surface: Smooth, non-marring profile for pipe protection
• Safety Factor: 3:1 (compliant with EN 13155:2003)
• Standards Compliance: Meets ANSI B30.20 lifting equipment standards
• Operating Temperature Range: -20°C to +100°C
• Applications: Lifting and positioning large steel, concrete, or coated pipes in industrial, construction, and fabrication settings

The Topal F10 0-100 Pipe Hook provides professionals with the lifting strength and safety performance needed for demanding pipe handling operations each and every time.
