Tractel Mobile GripWinch® MG505-50 Wire Rope Hoist — 500 kg (1,100 lb) Capacity, Two-Speed, Three-Phase, 17/33 fpm (5/10 m/min)
Tractel Mobile GripWinch® MG505-50 Wire Rope Hoist — 500 kg (1,100 lb) Capacity, Two-Speed, Three-Phase, 17/33 fpm (5/10 m/min)

  • Guaranteed Fitment

    Always the correct part

  • In-House Experts

    We know our products

  • Added Value

    FREE in house engineering and design assistance

  • Wordwide Delivery

    Free shipping on all Harrington orders over 500LBS

Tractel Mobile GripWinch® MG505-50 Wire Rope Hoist — 500 kg (1,100 lb) Capacity, Two-Speed, Three-Phase, 17/33 fpm (5/10 m/min)

Write a Review
$32,536.99
SKU: MG505-50
Weight: 160.00 LBS
Width: 29.10 (in)
Height: 22.00 (in)
Depth: 18.90 (in)
Shipping: Calculated at Checkout
Adding to cart… The item has been added
Tractel Mobile GripWinch® MG505-50 Wire Rope Hoist — 500 kg (1,100 lb) Capacity, Two-Speed, Three-Phase, 17/33 fpm (5/10 m/min)

Tractel Mobile GripWinch® MG505-50 Wire Rope Hoist — 500 kg (1,100 lb) Capacity, Two-Speed, Three-Phase, 17/33 fpm (5/10 m/min)

$32,536.99
Description

Tractel Mobile GripWinch® MG505-50 Wire Rope Hoist — 500 kg (1,100 lb) Capacity, Two-Speed, Three-Phase, 17/33 fpm (5/10 m/min)

The Mobile GripWinch MG505-50 is a versatile hoist designed for applications requiring precise lifting and pulling control. Its dual-speed operation, combined with rugged portability, makes it ideal for construction, maintenance, and industrial material handling.

Product Description

Equipped with a three-phase electric motor rated at 3.7/5.5 amps, the MG505-50 lifts to 500 kg (1,100 lb) at selectable speeds of 17 or 33 ft/min (5 or 10 m/min). It accommodates up to 160 ft (50 m) of 5/16 in. (8.4 mm) wire rope, giving you flexibility for longer lifts or varied jobsite setups.

The traction-based drive ensures users smooth operation at both speeds, while the design makes it easy to transport and install. Simple controls allow operators to lift or lower loads safely and efficiently.

Safety features such as automatic braking and load control give operators confidence, and the MG505-50’s low-maintenance design helps minimize downtime while maximizing reliability.

Key Specifications

  • Rated Capacity: 500 kg (1,100 lb)
  • Motor Type: Two-speed, three-phase electric motor, 3.7/5.5 A
  • Lifting Speeds: 17 / 33 ft/min (5 / 10 m/min)
  • Maximum Wire Rope Length: 160 ft (50 m)
  • Wire Rope Diameter: 5/16 in. (8.4 mm)
  • Drive System: Traction-based for smooth lifting and pulling
  • Controls: Easy-to-use up/down operation
  • Safety Features: Automatic brake, load control
  • Applications: Mobile lifting, pulling, scaffold or material handling
  • Maintenance: Simple, low-maintenance design

Why Choose the Mobile GripWinch MG505-50?

  • Dual-speed operation for precise control of loads
  • Smooth, consistent lifting across different rope lengths
  • Portable and rugged design for versatile jobsite use
  • Built-in safety features for operator protection
  • Low-maintenance for long-term reliability
Warranty Information
Tractel offers various warranties depending on the product, with a general warranty of 24 months on products manufactured by the seller for defects in materials and workmanship. Some specific products, like the tralift™ TT Electric chain hoist, may have a longer 3-year warranty. The warranty typically excludes issues from improper storage, assembly, maintenance, use, or unauthorized modifications and does not cover normal wear or paints.  Key Aspects of a Tractel Warranty:  Duration: The standard warranty period is 24 months (two years) from the date on the order invoice. Coverage: The warranty covers defects in materials and workmanship. Exclusions: The warranty generally does not cover: Improper storage or assembly. Insufficient maintenance or failure to follow operating instructions. Abnormal working conditions. Normal wear and tear. Willful or negligent damage. Modifications or repairs by personnel not certified by Tractel. Paints and coatings. How to Get More Information:  Check Product-Specific Details:  Always refer to the product's documentation or visit the Tractel US website for the exact warranty terms for your specific item. Contact Tractel:  For clarification on a specific warranty or to inquire about a potential claim, contact Tractel directly.
