Product Description:
The Safety Rail Co. 10' Cantilever Gate, Single, Yellow is a vertical-lift loading dock gate for a 10 ft clear opening. The aluminum gate arm lifts vertically and auto-lock in the upright position, so the gate needs no extra floor clearance and does not obstruct floor traffic when open, and pneumatic-assist struts help with opening and closing. The single-arm model is intended for standard dock doors. Closed, it provides a 42 in top rail and 21 in mid rail; open, it requires 163 in of height. The steel plate stanchion mounts to concrete or bar grating on a flat, level surface with the concrete anchors provided. It provides pedestrian and forklift access control for material handling areas and shipping and receiving docks.

Product Info:
•  Brand: Safety Rail Co.
•  SKU: 400785
•  Product Type: Cantilever lift gate, single arm
•  Clear Opening: 10 ft
•  Open Height: 163"
•  Closed Height: 42" top rail, 21" mid rail
•  Dimensions: 138 x 8 x 43"
•  Finish: Powder-coated safety yellow
•  Material: Gate arm: aluminum square tube; stanchion: steel plate
•  Mounting Depth: 10"
•  Operation: Lifts vertically; pneumatic-assist struts; auto-locks upright
•  Mounting Requirements: Concrete or bar grating substrate; flat, level surface
•  Included: Concrete anchors
•  Load Testing: Tested for 200 lb force in a downward or outward direction
•  Installation Time: Approx. 30 minutes
•  Standards/Certifications: OSHA 1910.29(b)(3) & (b)(4) and 1926.502(b)(3) & (b)(4); AWS D1.1 & D1.3 (American Welding Society certified)
•  Country of Origin: USA
