RAIL CONCAVE 75 FT RADIUS- Conductix XA-1C43805G03

The XA_1C43805G03 is a factory-curved, concave-profile conductor bar section with a 75_ft radius, engineered for use in curved trajectories of C_Series Saf_T_Bar installations. By providing a precise bend, it enhances collector shoe engagement, ensures smooth current pickup around bends, and reduces on-site installation complexity. Ideal for overhead cranes, conveyors, and monorail systems, this rail eliminates the need for manual field-curving and maintains consistent electrical performance through curves Key Features 75_ft radius concave curve — ensures precise, factory-bent profiling. Improved collector tracking — optimized contact performance through curvature. Drop-in installation — avoids the need for time-consuming field bending. C_Series compatible — seamlessly integrates with standard C_Series conductor systems. Technical Specifications Specification Details Part Number XA_1C43805G03 Rail Profile Concave (curved section) Radius 75_ft (≈_22.9_m) Intended Use Curved conductor-bar paths in C_Series Installation Factory-formed drop-in section Applications Overhead crane runways, monorails, conveyors
