The XA_6972C98G04 is a complete expansion_gap kit in beige, engineered to accommodate a standard 2_ air gap between conductor segments in high-current C_Series systems. It includes jumper cables and power-feed components to ensure unbroken power flow despite rail contraction and expansion due to temperature changes. Recommended spacing is ~100_ft for copper rails and ~150_ft for steel rails, with gap assemblies installed at these intervals
. Designed for 100–350_A capacities, it suits industrial applications like overhead cranes, conveyors, and monorails where environmental robustness and electrical reliability are essential.
Key Features
Pre_assembled beige kit — covers a 2_ expansion gap with integrated jumpering.
Maintains power continuity — jumper conductors ensure seamless current across gaps.
Thermally resilient — gap placement based on conductor material and temperature rise
100–350_A capacity — suitable for typical C_Series heavy-duty systems.
Snap_on installation — designed for simple, field-ready assembly in industrial environments.
Technical Specifications
Specification Details
Part Number XA_6972C98G04
Color / Finish Beige PVC extrusion
Gap Width 2.00_ adjustable air space
Current Capacity 100–350_A conductor systems
Recommended Spacing ~100_ft for copper, ~150_ft for steel conductor runs
Components Included Gap housing, jumper conductors, power feeds
Applications Overhead cranes, conveyors, monorails—industrial rail systems
