The XA_4899B65H03 is a compact alignment plate engineered for pressure-style (PS) Saf_T_Bar C_Series collector and splice assemblies. Constructed from durable metal, it guarantees precise spacing and alignment of bar segments or collector components, reducing binding and ensuring uninterrupted electrical contact. At only 0.04_lb, this lightweight yet robust plate simplifies installation and contributes to long-term system reliability in overhead cranes, conveyors, and monorails.
Key Features
Precision dimensions — at 1.75_ _ 0.75_ _ 0.125_, it ensures accurate alignment of components.
Pressure-style (PS) compatibility — tailored for PS-style collector and splice assemblies.
Durable metal construction — supports mechanical stability under load.
Lightweight (0.04_lb) — adds minimal weight to collector systems.
Easy integration — designed for tool-free installation during assembly or maintenance.
Technical Specifications
Specification Details
Part Number XA_4899B65H03
Dimensions 1.75_in _ 0.75_in _ 0.125_in thick
Weight ≈_0.04_lb (≈_18_g)
Material Metal (typically steel or plated alloy)
Function Ensures precise positioning in PS assemblies
Compatibility Saf_T_Bar C_Series PS collector/splice kit
