PL Series 2000lb capacity 24 x 36 platform

Write a Review
$1,698.12
SKU: PL36
Weight: 315.00 LBS
Shipping: Calculated at Checkout
Adding to cart… The item has been added
PL Series 2000lb capacity 24 x 36 platform

PL Series 2000lb capacity 24 x 36 platform

$1,698.12

PL36 – A mechanical post lift table with a 2,000 lb capacity, a 24″ × 36″ platform, and hand-crank operation—ideal for precise, power-free lifting and positioning in tight workspaces or mobile setups.

Product Description

Need a reliable lifting solution when power isn’t an option? The PL36 Mechanical Post Lift Table offers high-capacity strength, precise control, and simplicity in operation. Built for workshop floors, maintenance bays, production areas, and anywhere you require dependable mechanical lifting, this post lift table allows you to raise and position heavy loads smoothly—without electricity.

With a 2,000 lb (907 kg) rated capacity, the PL36 is well suited for heavy components, molds, tooling, and material loads. Its 24″ × 36″ platform gives you a stable surface while keeping the overall footprint compact enough to pass through narrow aisles or fit beside workstations.

The lifting system is purely mechanical: a hand crank drive turns four acme screw posts, delivering precise height adjustment and positive load holding (no drift). The crank mechanism offers dual-speed operation—one speed for rapid elevation, the other for fine adjustment—so you can move loads quickly or make subtle alignment changes. Because it’s manual, the unit works anywhere, including power-restricted areas or remote locations.

Stability and mobility are engineered into the PL36. It rides on two rigid and two swivel phenolic casters, allowing easy rolling to the desired location. A foot-operated floor lock secures the unit during lifting or positioning operations, ensuring a safe and stable working platform.

Constructed from heavy-duty welded steel, the PL36 includes guide posts to maintain alignment through the travel range and a robust frame designed to resist twisting or misalignment under load. Its mechanical simplicity means fewer components to maintain—no motors, no hydraulics, no batteries.

Whether you need to lift, position, or stage heavy materials in a power-free setting, the PL36 Mechanical Post Lift Table offers dependable performance, precision, and rugged durability in tight or mobile environments.

Specifications

  • Model / SKU: PL36

  • Type: Mechanical post lift table

  • Load Capacity: 2,000 lb (907 kg)

  • Platform Size: 24″ (W) × 36″ (L)

  • Lift Mechanism: Manual hand-crank drive

  • Lifting Posts: Four self-locking acme screw posts (no load drift)

  • Crank Operation: Dual-speed crank (fast and fine modes)

  • Mobility: Two rigid and two swivel phenolic casters

  • Locking Mechanism: Foot-operated floor lock for secure positioning

  • Frame: Heavy-duty welded steel with guide posts for stability

  • Approximate Travel Range: ~ 18″ vertical travel (typical for mechanical post tables)

  • Ideal Uses: Tool & die handling, assembly support, staging heavy parts, maintenance operations

Limited Warranty Policy Presto Lifts warrants all of its products (excluding PowerStak) against defects in the welded structural frame and, if applicable, scissor legs from faulty material and workmanship for a period of five years from the date of invoice. A lifetime limited warranty is provided for the Airstroke Actuator™ in all pneumatic lifts against any defect due to faulty material or workmanship. All other components have a limited warranty against defects in faulty material and workmanship for a two year period from the date of invoice and 30 day limited warranty on labor. Please note that prior authorization from Presto Lifts is required on all warranty work. There are no implied warranties of any kind, more specifically, there are no warranties of merchantability or fitness for any particular purpose. Presto Lifts’ sole warranty shall be as set forth in this limited warranty. Presto Lifts will elect to repair or replace a defective component without charge if any components should become defective within the limited warranty period. Proof of purchase is required for warranty. The charge for shipping the defective component is the responsibility of the buyer and must be accompanied with an RGA number. The shipping charge to return the component to the buyer is the responsibility of Presto Lifts, Inc. This limited warranty does not cover labor expense for removal or reinstallation of components after thirty days. This limited warranty shall not cover, among other things: damages resulting from foreign matter or water, failure to provide reasonable and necessary maintenance, and if applicable, use of product while charger is plugged into an AC outlet, or failure to follow operating instructions. The limited warranty is not valid for damage resulting from negligence, accident, unreasonable use, abuse, or misuse, exceeding data plate capacities or altering the product without Presto Lifts authorization. Presto Lifts expressly disclaims and excludes any liability for consequential, incidental, indirect or punitive damages or financial loss to people or property resulting from any breach of warranty or the operation or failure of this product. Presto Lifts makes no representation that this product complies with local, state, or federal safety/product standards codes. Should this product fail to comply in any way with those codes, it shall not be considered a defect of materials or workmanship. Presto Lifts shall not be held liable for any damages resulting from noncompliance. It is the dealer’s responsibility to exercise this limited warranty. This limited warranty is provided to the original purchaser (defined as the original end user) and is nontransferable. This constitutes the complete and final agreement involving Presto Lifts and limited warranty obligations for products. PowerStak Warranty Policy Presto Lifts warrants the PowerStak against defects in the welded structural frame and AC motors on lifts equipped with an AC power unit from faulty material and workmanship for a period of one (1) year from the date of invoice. Presto Lifts warrants the PowerStak against defects in the mast, fork carriage, chains, pumps, DC motors, controllers, cylinders, and wiring harnesses from faulty material and workmanship for a period of one (1) year from the date of invoice. All wear items such as batteries, wheels, motor brushes, seals, bearings, hydraulic hoses, all switches, battery chargers, and forks have a limited warranty against defects in faulty material and workmanship for a ninety (90) day period from the date of invoice and a thirty (30) day limited warranty on labor. Please note that prior authorization from Presto Lifts is required for all warranty work.
