NERP-FG Electric Food Grade Chain Hoist with Push Trolley Lift-Capacity 1/2 Tons NERP005L-FG Electric Chain Hoist with Push Trolley HARRINGTON

Write a Review
$6,499.97 - $6,836.15
SKU: NERP005L-FG-10
Condition: New
Availability: In stock
Weight: 82.00 LBS
Shipping: Free Shipping
Part Number: NERP005L-FG
Color: White
Hoist Lift: 10, 15, 20
Product: Electric Chain Hoist, 1,000 lb, Push Trolley, White=Hoist Mount=Push Trolley
Includes: Chain Container, Quick Disconnect Plugs On Pendant and Power Cord
Lift Speed: 15 fpm
Housing Width: 8 1/2 in
Manufacturers Warranty Length: 10 yr Brake Warranty, 3 yr
Housing Depth: 16 5/16 in
Housing Length: 22 3/8 in
For Minimum Beam Flange Width: 2 9/32 in
For Maximum Beam Flange Width: 4 in
For Maximum Beam Height: Not Applicable
MFR Warranty Length: 1 yr
Body Width: 8 1/2 in
Body Depth: 16 5/16 in
For Minimum Beam Height: 3 3/16 in
Body Length: 22 3/8 in
Minimum Radius Curve: 43 5/16 in
Controller Cord Length: 6 ft
Trolley Wheel Diameter: 2 23/64 in
Lifting Hook Opening Width: 16 5/16 in
Minimum Retracted Length: 16 5/16 in
Load Capacity: 1,000 lb
Minimum Between Hooks: 16 5/16 in
Motor HP: 0.75 hp
Phase: 3
Standards: ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70
Voltage: 230/460V
Fits Brand: Harrington Hoists Inc
Lubrication: Food Grade Oil
Reeving: 1
Thermal Protection: Yes
Control Cord: 6 ft
Amps @ Low Volts: 3.4 A
Number of Speeds: 1
Trolley Configuration: Push Trolley
Trolley Speed: Not Applicable
Features: FDA Approved Food-Safe Oil, Grease and Lubricants
Lifting Hook Material: Carbon Steel
Includes Clutch: Clutch Included
Overload Protection Included: Yes
Brake Type: DC Current
Chain Grade: Grade 80
Maximum Lift Speed: Not Applicable
Included Components: Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook
Fixed Lift Speed: 15 fpm
Clutch Type: Friction
Minimum Lift Speed: Not Applicable
Pendant IP Rating: IP65
Chain Finish: Nickel Plated
Controls: Push Button Pendant=Mount Type=Push Trolley
Starts and Stops per Hour: 360
Duty Classification: H4
Maximum Pulling Capacity: Not Applicable
Number of Reeves: 1
Motor Horsepower: 3/4 hp
Headroom: 16 5/16 in
Includes Brake: Brake Included
For Outdoor Use: Yes
Lifting Hook Type: Swivel Hook with Safety Latch
Maximum Lifting Capacity: 1,000 lb
Current at Minimum Voltage: 3.4 A
Trolley Wheel Material: Steel
Current at Maximum Voltage: 1.7 A
Body Finish: Epoxy Painted
Number of Load Chains: 1
Body Material: Aluminum
Trolley IP Rating: Not Applicable
Programmable: Non-Programmable
Adding to cart… The item has been added
NERP-FG Electric Food Grade Chain Hoist with Push Trolley Lift-Capacity 1/2 Tons NERP005L-FG Electric Chain Hoist with Push Trolley HARRINGTON

NERP-FG Electric Food Grade Chain Hoist with Push Trolley Lift-Capacity 1/2 Tons NERP005L-FG Electric Chain Hoist with Push Trolley HARRINGTON

$6,499.97 - $6,836.15

NERP-FG Electric Food Grade Chain Hoist with Push Trolley Lift-Capacity 1/2 Tons NERP005L-FG Electric Chain Hoist with Push Trolley HARRINGTON

$6,499.97 - $6,836.15

Elevate your food processing and packaging operations with the HARRINGTON NERP-FG Electric Food Grade Chain Hoist, model NERP005L-FG. Designed specifically to meet the rigorous standards of the food industry, this electric hoist ensures safe and reliable lifting capabilities of up to 1/2 tons.

Constructed from durable, food-grade materials, the NERP005L-FG adheres to the highest hygiene standards, safeguarding the quality and safety of your food products throughout the lifting and transport process. Its robust build is optimized to withstand the demanding conditions typical in food handling environments, enhancing both reliability and longevity.

Equipped with a user-friendly push trolley, this hoist simplifies the movement and positioning of loads, streamlining workflows and enhancing productivity in your facility. No longer will you need to strain or struggle with heavy lifting; the expertly designed NERP005L-FG transforms tasks into manageable operations, allowing for quick adjustments and seamless transportation of goods.

This electric chain hoist is not only a tool but a trusted partner in your operations, delivering dependable performance day in and day out while ensuring compliance with strict food industry regulations. By investing in the NERP005L-FG, you gain peace of mind knowing that your lifting equipment is built to uphold the highest standards of safety and hygiene.

Transform your food processing or packaging endeavors today with the HARRINGTON NERP-FG Electric Food Grade Chain Hoist. Experience the efficiency and reliability that comes from using cutting-edge technology specifically designed for the food industry.

Buyer must notify HHI in writing within sixty (60) days of discovery of any alleged defect, if within the applicable warranty period. All products sold by HHI are warranted to be free from defects in material and workmanship from date of shipment by HHI for the following periods: 1 year – Electric and Air Powered Hoists (excluding (N)ER2 Hoists and EQ/SEQ Hoists), Powered Trolleys, Powered Tiger Track Jibs and Gantries, Crane Components, Below the Hook Devices, Spare / Replacement Parts 2 years – Manual Hoists & Trolleys, Beam Clamps 3 years – (N)ER2 Hoists, EQ/SEQ Hoists, (T)EM/(T)SEM hoists, and RY Hoists 5 years – Manual Tiger Track Jibs and Gantries, Hoist Motor Brakes for EQ/SEQ, (T)EM/(T)SEM, and RY 10 years – (N)ER2 Brake, TNER Hoist Motor Brake The product must be used in accordance with manufacturer’s recommendations and must not have been subject to abuse, lack of maintenance, misuse, negligence, or unauthorized repairs or alterations. Should any defect in material or workmanship occur during the above time period in any product, as determined by HHI’s inspection of the product, HHI agrees, at its discretion, either to replace (not including installation) or repair the part or product free of charge. For customers in the U.S., delivery shall be made F.O.B. HHI’s place of business. For international customers, delivery shall be made FCA HHI place of business, United States of America (Incoterms 2010). No warranty claim will be honored without a valid proof of purchase. Customer must obtain a Return Goods Authorization as directed by HHI or its published repair center prior to shipping product for warranty evaluation. An explanation of the complaint must accompany the product. Product must be returned freight prepaid. Upon repair, the product will be covered for the remainder of the original warranty period. Replacement parts installed after the original warranty period will only be eligible for replacement (not including installation) for a period of one year from the installation date. If it is determined there is no defect, or that the defect resulted from causes not within the scope of HHI’s warranty, the customer will be responsible for the costs of returning the product. HHI DISCLAIMS ANY AND ALL OTHER WARRANTIES OF ANY KIND, EXPRESSED OR IMPLIED, AS TO THE PRODUCT’S MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. HHI WILL NOT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY OR FOR INCIDENTAL, CONTINGENT, SPECIAL OR CONSEQUENTIAL DAMAGES, LOSS OR EXPENSE ARISING IN CONNECTION WITH THE USE OR MISUSE OF THE PRODUCTS, REGARDLESS OF WHETHER THE DAMAGE, LOSS OR EXPENSE RESULTS FROM ANY ACT OR FAILURE TO ACT BY HHI, WHETHER NEGLIGENT OR WILLFUL, OR FROM ANY OTHER CAUSE
