The Machining & Welding 15000 LB 10 FT Twin Hoist Lift Beam coordinates two hoists on a single beam, spreading 15,000 pounds of capacity across a 10 foot length for long, awkward, or heavy loads.

This beam is a common fit for long structural members, pipe, machinery, and other loads where a single center pick point would cause the load to tip or sag.

Heavy gauge steel construction keeps deflection low across the full span, which matters when two independently operated hoists are sharing one load.

This approach lets shops handle oversized loads using two hoists they already have, instead of investing in a single higher capacity unit.

From production floors to rail yards to municipal utility crews, this style of equipment gets used wherever a load needs to move safely between two points. Standardizing on purpose-built lifting equipment also makes training new operators easier, since the rigging setup stays consistent from lift to lift instead of changing based on whatever hardware happens to be nearby.

Before putting any lifting equipment into service, verify it matches your hoist or crane setup and confirm the rated capacity covers your heaviest expected load with margin to spare. Routine inspection of welds, pins, and connection hardware helps catch wear before it becomes a safety issue. Keep a simple inspection log if your facility does not already have one, since tracking wear over time makes it easier to plan replacement before a part actually fails in use.

Well-built rigging hardware holds its rated capacity through years of regular use, provided it is inspected and stored properly between jobs. A dry, organized storage area away from corrosive chemicals or extreme temperature swings goes a long way toward extending the service life of steel components.

Details on capacity, dimensions, and hardware are listed below for a quick comparison against your requirements.

With swivel latch hooks at both ends, the Machining & Welding 15000 LB 10 FT Twin Hoist Lift Beam is set up for smooth, controlled twin hoist lifts.

Product Info:
•  Working Load Limit: 15,000 lbs
•  Beam Length: 10 ft
•  End Fittings: Swivel latch hooks
•  Style: Twin hoist, dual lift point
•  Frame Material: Structural steel
•  Shipping Weight: 580 lbs
