EXPANSION JT ASSY INSTALL KIT PC CVR Conductix XA-6D61061G02

The XA_6D61061G02 provides everything needed to install a high-reliability expansion joint in Saf_T_Bar C_Series electrification systems during field assembly. Rated up to 350_A, the kit includes jumper cables, copper rail inserts, structural hanger clamps, end caps, and a tough polycarbonate protective cover. Ideal for managing thermal rail movement and maintaining electrical continuity, it enables seamless collector travel across joint zones. With factory-packaged components and easy on-site assembly, it's perfect for retrofit installations or new builds requiring robust gap management Key Features Full installation kit — includes clamps, copper inserts, jumper cables, end caps, and housing cover. 350_A current capacity — supports medium to heavy-duty systems. Polycarbonate joint cover — offers superior mechanical protection and insulation. Field-friendly — pre-packaged for straightforward on-site assembly. Thermal expansion ready — maintains continuous electrical function across movement zones. Technical Specifications Specification Details Part Number XA_6D61061G02 Series Compatibility Saf_T_Bar C_Series (100–350_A systems) Current Rating 350_A continuous Includes End caps, copper rail inserts, jumper leads, hanger clamps, PC cover Installation Type On-site field assembly; no special fabrication Primary Purpose Creates structurally stable expansion-joint with electrical continuity Recommended Placement Approx. every 150_ft for steel rails; 100_ft for copper rails Installation Tips Pair with tandem collector assemblies to ensure uninterrupted power pickup across the joint. Mount joint near system midpoints if temperature cycles vary (indoors vs outdoors). Follow torque specs for jumper and clamp connections—refer to product manual.
