Detroit Hoist Monorail Hoist, 11 Ton Capacity, 21 FPM Lift Speed, 80 FPM Trolley Speed, Model DB22M38-21

Write a Review
$26,000.00
$22,750.00
(You save $3,250.00 )
SKU: DB22M38-21
Weight: 1,900.00 LBS
Shipping: Calculated at Checkout
Adding to cart… The item has been added
Detroit Hoist Monorail Hoist, 11 Ton Capacity, 21 FPM Lift Speed, 80 FPM Trolley Speed, Model DB22M38-21

Detroit Hoist Monorail Hoist, 11 Ton Capacity, 21 FPM Lift Speed, 80 FPM Trolley Speed, Model DB22M38-21

$26,000.00
$22,750.00
(You save $3,250.00 )

Detroit Hoist Monorail Hoist, 11 Ton Capacity, 21 FPM Lift Speed, 80 FPM Trolley Speed, Model DB22M38-21

$26,000.00
$22,750.00
(You save $3,250.00 )

The DB22M38-21 Monorail is a top-tier lifting solution designed to meet the rigorous demands of modern industrial applications. With an outstanding capacity of 11.00 tons, this hoist is engineered to handle substantial loads reliably and efficiently, while its versatile installation options make it ideal for a variety of mounting configurations.

Providing significant height capabilities and rapid movement, the DB22M38-21 maximizes productivity in any material handling operation. Featuring a robust 13.4 kW hoist motor, this monorail hoist is built to lift heavy materials smoothly, ensuring the highest performance standards in challenging environments. Whether you're dealing with tall or bulky items, you can trust the performance and reliability of this advanced lifting equipment.

  • Hoist Lift Speed: A maximum lift speed of 21.00 feet per minute (FPM) enhances operational efficiency.
  • Trolley Speed: Achieve rapid horizontal load movement with a maximum speed of 80.00 FPM.
  • Durable Construction: Crafted with weather-resistant features, compliant with CMAA Class D standards for robust durability.
  • Innovative Control System: Closed-loop vector Variable Frequency Drive (VFD) technology for precise speed and torque management.
  • 3-Part Reeving System: Supports a lift height of 38 feet and 8 inches for tall load handling.
  • Power Supply Compatibility: Operates on a 230VAC, 3-phase electric supply for seamless integration into existing systems.
  • High-Quality Components: Equipped with premium-grade graphite ductile iron wheels and sheaves for unrivaled durability.
  • Advanced Safety Features: Includes motor overload protection and dynamic braking to ensure operational safety.
  • Easily Adjustable Limits: Features adjustable upper and lower electronic encoder limits for precise operation.
  • Enhanced Speed Options: 90 Hz hoist speed can be enabled upon request for increased performance at rated loads.

This DB22M38-21 Monorail represents a perfect blend of power, control, and reliability, making it a necessary addition to any industrial operation that prioritizes efficiency and safety. Streamline your material handling processes today by choosing a lifting solution that guarantees performance and versatility.

The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
