Product Overview
Atlas Titon Electric Chain Hoist – TEH-3-020-10
2 Ton Capacity | 10-Foot Lift | Three-Phase | Single Speed
The Atlas TEH-3-020-10 Titon Electric Chain Hoist is a rugged, high-capacity lifting solution engineered for demanding industrial environments. Hoist has a 2-ton (4,400 lbs) rated capacity and a 10-foot lift height, this hoist delivers superior strength, consistent performance, and long-term reliability. Designed for safe and efficient material handling, it features a heavy-duty motor, reinforced load chain, and comprehensive safety controls.
Features
- 2 Ton Load Capacity: Lifts up to 4,400 lbs with dependable, controlled motion.
- 10-Foot Lift Height: Standard vertical reach suited for most overhead lifting applications.
- Industrial-Grade Load Chain: Grade 80 alloy steel, black oxide-coated for durability and corrosion resistance.
- Three-Phase Power: High-performance motor designed for continuous use in industrial settings.
- Electromagnetic Load Brake: Automatically activates to hold the load securely during lifts and stops.
- Low-Voltage Pendant Control: 24V push-button pendant ensures operator safety and responsive control.
- Forged Top Hook Suspension: Provides a secure mount to a fixed point or trolley system.
- IP54 Enclosure Rating: Dust and water-resistant housing protects internal components in harsh environments.
Specifications
- Model: TEH-3-020-10
- Rated Capacity: 2 Ton (4,400 lbs)
- Lift Height: 10 feet
- Lifting Speed: Approx. 8–10 feet per minute (varies slightly by configuration)
- Load Chain: Grade 80 alloy steel, black oxide finish
- Brake System: Electromagnetic load brake
- Motor Protection: Thermal overload protection
- Pendant Control: 24V low-voltage, push-button
- Suspension: Top hook
- Enclosure Rating: IP54 (dust and splash resistant)
- Duty Cycle: 30% ED (intermittent duty)
- Power Supply: Three-phase (voltage specified at time of order)
- Approximate Weight: 180–200 lbs
- Warranty: 3-Year Limited
- Country of Origin: China
The TEH-3-020-10 is designed for users who require strength, safety, and efficiency when handling heavy materials. It is ideal for manufacturing, construction, steel fabrication, and other heavy-duty lifting environments.
