Product Overview
Introducing the enhanced Spanco 301-100 Wall Mounted Jib Cranes, the epitome of economical overhead lifting devices designed to handle loads weighing up to 1,000 lbs effortlessly. These versatile jib cranes feature booms ranging from 8' to 30', capable of rotating up to 200° to meet diverse application needs.
Engineered for optimal efficiency, these wall-mounted jib cranes boast a unique design with wall brackets and a tie rod supporting the boom, eliminating the need for additional support under the beam. This innovative construction allows a trolley to traverse nearly the entire length of the boom, enhancing operational flexibility.
Crafted for stability and precision, the 1,000 LB wall-mounted jib cranes adhere to the highest engineering standards. Utilizing a standard I-beam and a single tie rod, they eliminate off-center loading issues, ensuring a reliable lifting experience. The top and bottom wall brackets employ a formed steel channel with two bronze bushings, bronze thrust washers, and formed tie-rod clevises for robust structural support.
Incorporating a commitment to quality, all bolted connections are engineered in double shear, providing additional strength. Swivel connections on these 1-ton wall-mounted jib cranes feature bronze bushings and grease fittings, reducing rotational friction and promoting a prolonged service life while keeping maintenance requirements to a minimum.
Compliance with industry standards is paramount, and Spanco Wall Mounted Jib Cranes proudly meet AISC Steel Construction Manual, OSHA 1910.179, ANSI B30.11, AWS D1.1/D1.6, and CMAA 74 standards.
Built to order, these 1-ton Wall Mounted Jib Cranes offer a short lead time, ensuring prompt delivery to meet your lifting needs with unparalleled efficiency and precision. Upgrade your workspace with the reliability and innovation embodied in Spanco's Wall Mounted Jib Cranes.
Capacity:1000 lbs
Span:12' - 0''
Clear Span:10' - 10''
Support Bracket Centers:3'-9"
Thrust/Pull:4350 lbs
Beam Size:S6x12.5#
001 301-050-12 1
JIB, WALL TIE ROD SUPPORTED 1/2 TON (INDOOR)
Beam Bracket Center: 1'-9"
Tie Rod Length: 9'-5"
Flange Width: 3.33''
Coating & Painting: PAINT, SPRAY YELLOW
( Hoist not included must be purchased separately )
