Spanco 301 Series Wall-Mounted Tie-Rod Supported Jib Crane - 1 Ton - 10 ft Span
video
Spanco 301 Series Wall-Mounted Tie-Rod Supported Jib Crane - 1 Ton - 10 ft Span

  • Guaranteed Fitment

    Always the correct part

  • In-House Experts

    We know our products

  • Added Value

    FREE in house engineering and design assistance

  • Wordwide Delivery

    Free shipping on all Harrington orders over 500LBS

Spanco 301 Series Wall-Mounted Tie-Rod Supported Jib Crane - 1 Ton - 10 ft Span

Write a Review
$3,407.00
$2,768.19
(You save $638.81 )
SKU: 301-100-10
Availability: Subject to Availability
Weight: 270.00 LBS
Shipping: Calculated at Checkout
Capacity: 1,000 - 2,499 lbs
Type / Mounting: Wall Bracket
Span / Boom Length: 10' 0"
Adding to cart… The item has been added
Spanco 301 Series Wall-Mounted Tie-Rod Supported Jib Crane - 1 Ton - 10 ft Span

Spanco 301 Series Wall-Mounted Tie-Rod Supported Jib Crane - 1 Ton - 10 ft Span

$3,407.00
$2,768.19
(You save $638.81 )
Description

The Spanco 301 Series Wall-Mounted Jib Crane is the pinnacle of material handling solutions, specifically designed for indoor applications with a capacity of 2000 lbs. With an impressive span of 10 feet and a clear span of 8 feet 10 inches, this jib crane offers precision engineering and exceptional performance for lifting heavy materials in confined spaces.

Crafted with robust construction and operational efficiency in mind, the Spanco 301 Series features all bolted connections in double shear, ensuring maximum reliability. Its swivel connections, equipped with bronze bushings and grease fittings, facilitate smooth rotation while significantly extending the service life of the crane. The attention to detail in engineering makes this jib crane an indispensable asset for any facility prioritizing efficiency and safety.

  • Capacity: 2000 lbs, designed to handle substantial loads with ease.
  • Span: 10 feet, ideal for maximizing workspace accessibility.
  • Clear Span: 8 feet 10 inches, providing the necessary clearance for lifting operations.
  • Support Bracket Centers: 3 feet, thoughtfully positioned for optimal load distribution.
  • Thrust/Pull: S6x12.5#, tailored for superior performance under stress.
  • Beam Size: 8610 lbs, engineered for enhanced strength and stability.

Additional exceptional features of the Spanco 301 Crane include a beam bracket center strategically located at 1 foot 6 inches to optimize load distribution and enhance balance during lifting. The tie rod length measures 7 feet 4 inches, reinforcing structural integrity and stability throughout material handling tasks. To further ensure durability, the crane boasts a 3.33-inch flange width, fortifying its structural components against wear and tear.

Visual appeal and functionality go hand in hand with the Spanco 301 Series, as it is coated with a protective layer of yellow spray paint. This not only enhances the crane's aesthetics but also provides resistance against environmental threats, promoting prolonged longevity and corrosion resistance. Though the hoist is not included and must be purchased separately, the Spanco 301 Series serves as a versatile solution in any industrial environment.

With the Spanco 301 Series Wall-Mounted Jib Crane—Tie-Rod Supported, elevate your material handling efficiency while enjoying the benefits of simplified maintenance and outstanding durability. This crane exemplifies Spanco's commitment to excellence and innovation in material handling technology, making it a reliable choice for professionals across various industries.

Warranty Information
PtP Spanco, Inc. warrants its products to be free from defects in material and workmanship as follows: manual systems and equipment for ten years, and motorized systems and equipment along with paint and finishes for non-aluminum components for two years. Specifically, manual workstation bridge crane, jib crane, and gantry crane products are warranted against defects in material and workmanship for ten years or 20,000 hours from the date of shipment to the first retail purchaser, covering only nonwearable parts except that wearable wheels on manually operated workstation end trucks and hoist trolleys are also included; motorized equipment is warranted for two years or 4,000 hours from the date of shipment, and paint and finishes are warranted for two years, with coating-related claims requiring documentation of the product's application and environmental conditions from delivery through the time of claim. All warranty claims must be approved by PtP Spanco, Inc. before any work is performed, and its obligation is limited to repairing or replacing products at the factory or an approved location, with no other express, implied, or statutory warranties honored - including any warranty of merchantability or fitness for a particular purpose - and PtP Spanco, Inc. reserves the right to reject claims due to harsh or inappropriate environmental conditions. PtP Spanco, Inc. is not liable for indirect, incidental, or consequential damages (including lost profits, operating costs, loss of production, or travel expenses); components or accessories it did not manufacture; defective equipment or system failure caused by misuse, negligence, or improper installation or maintenance; equipment used beyond its rated capacity or service factors; unauthorized rework or modification; freight charges and damage caused by freight carriers; or loss, injury, or property damage resulting from failure or defective operation. Under the reimbursement disclaimer, written notice of any claimed system defect must be given within ninety (90) days of shipment, all reimbursement requests must include proper documentation, reimbursement is provided as a credit unless otherwise approved by PtP Spanco, Inc. management, labor reimbursement is capped at $90 per hour, and all reimbursement remains subject to PtP Spanco, Inc. management approval.
