The XA-8BC-30S-19-JC 8-Bar Collector is a compact, high-performance component engineered for efficient current transfer in mobile electrification systems. With a 30-amp rating, it’s well-suited for light to medium-duty applications. The jointed head (J-HD) provides flexibility and maintains consistent contact with the conductor bar during movement, reducing wear and ensuring stable power flow. Its composite base (C-BSE) is lightweight, corrosion-resistant, and designed for longevity. This model includes a 19-position guide tube (19 PGT), which ensures precise alignment within the conductor bar housing for optimal tracking and performance.
Key Features:
30A Capacity: Ideal for light-to-medium power mobile equipment.
Jointed Head (J-HD): Maintains stable electrical contact despite rail misalignment or vibration.
Composite Base (C-BSE): Durable, non-conductive material resists impact and corrosion.
19-Position Guide Tube (19 PGT): Provides accurate tracking and alignment within the conductor rail.
Compact Design: Suitable for tight spaces and efficient installations.
Technical Specifications:
System Type: 8-Bar Conductor System
Current Rating: 30 Amps
Mounting: Standard (non-lateral)
Head Type: Jointed Head (J-HD)
Base Type: Composite (C-BSE)
Guide Tube: 19-position
Application: Power collection for cranes, monorails, and other mobile electrified equipment
