Load Capacity
Load Capacity 10,000 lb
Hoist Lift 10 ft
Hoist Mount Geared Trolley
Hoist Overload Protection No
Pull to Lift Rated Load 92 lb
Housing Length 20 1/2 in
Housing Width 18 1/2 in
Housing Depth 16 in
Manufacturers Warranty Length 1 yr
For Min Beam Flange Height 5 3/32 in
Lifting Hook Opening Width 1 13/16 in
Body Depth 15 13/16 in
Body Width 18 5/16 in
Chain Length 11 ft
For Max Beam Flange Width 7 1/8 in
Minimum Retracted Length 20 5/16 in
For Min Beam Flange Width 5 1/8 in
For Max Beam Flange Height Not Applicable
Maximum Lifting Length 10 ft
Lever Length Not Applicable
Min Between Hooks 24 1/4 in
Hook Opening 1 51/64 in
Trolley Configuration Geared Trolley
Brake Weston Style Brake
Standards ANSI/ASME B30.16, ANSI/ASME HST-2M
Color Yellow
Features Integral Trolley
Overload Protection Included No
Resistance Properties Abrasion Resistant, Corrosion Resistant, Moisture Resistant, Wear Resistant
Body Material Die-Cast Aluminum
Brake Type Weston Style
Chain Material Manganese Alloy
Chain Grade Grade 100
Mount Type Geared Trolley
Included Components Safety Latch Hooks
Operating Position Vertical
Lifting Hook Material Carbon Steel
Lifting Hook Type Hook with Safety Latch
Includes Brake Brake Included
Maximum Pulling Capacity Not Applicable
Power Source Manual
Headroom 20 5/16 in
Number of Load Chains 1
Number of Reeves 3
Maximum Lifting Capacity 10,000 lb
Includes Clutch Clutch Not Included
