NER Electric Chain Hoist 15' Lift-Capacity 3 Tons NER030C Electric Chain Hoist HARRINGTON

Product Overview

The NER030C-15 HARRINGTON NER Electric Chain Hoist is the ultimate tool fortackling challenging lifting tasks. This robust hoist is built to withstand eventhe harshest conditions, guaranteeing top-notch performance every time. With alifting capacity of 15 feet and available in Capacity 3 Tons,this hoist is capable of handling heavy loads with ease. The NER030C-15 is equipped with cutting-edge technology and precision engineering,ensuring smooth and efficient operation. You can rely on this electric chain hoistto provide the power and reliability required for your most demanding lifting needs.Designed for heavy-duty applications, this hoist is perfect for industries such asconstruction, manufacturing, and warehousing.The NER030C-15 boasts a plethora of features that make it standout in the market.Its compact and lightweight design allows for easy installation and maneuverability,while the ergonomic handle ensures comfortable operation. The chain guidecontribution to smooth operation and exceptional performance.Safety is paramount when it comes to lifting equipment, which is why the NER030C-15is equipped with various safety features. The upper and lower limit switchesprovide added security, preventing overloading and ensuring safe operation. Thefriction clutch prevents damage to the hoist in case of accidental overload, thusextending the lifespan of the equipment. The thermal motor protection featureshuts down the hoist automatically to prevent overheating, further enhancing safety.Whether you need to lift heavy machinery, materials, or equipment, the NER030C-15HARRINGTON NER Electric Chain Hoist is up for the task. Its exceptional durabilityand performance make it a reliable and long-lasting investment. With its innovativefeatures and dependable operation, this electric chain hoist will exceed yourexpectations and streamline your lifting operations.Choose the NER030C-15 HARRINGTON NER Electric Chain Hoist for exceptional power,reliability, and precision. Experience peak performance and complete your toughlifting tasks effortlessly.

Product Specifications

.

Part Number:

NER030C-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 6,000 lb, 15 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Limit Switches, Plug-In Connections

Lift Speed:

17 fpm

Housing Width:

16 13/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

9 1/2 in

Housing Length:

27 11/16 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

16 13/16 in

Body Depth:

9 1/2 in

For Minimum Beam Height:

Not Applicable

Body Length:

27 11/16 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

15 ft

Controller Cord Length:

9 3/16 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 13/16 in

Minimum Retracted Length:

30 29/32 in

Load Capacity:

6,000 lb

Minimum Between Hooks:

32 15/16 in

Motor HP:

4.7 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

2

Thermal Protection:

Yes

Control Cord:

11 ft

Finish:

Electrostatic Enamel

Amps @ Low Volts:

16.4 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Dual Speed VFD, Easy Access Suspension, Extreme Duty Motor, Secondary Brake, Smart Brake Technology, State-Of-The-Art Chain Technology, Unique Smart Limit Option

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

17 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

2

Motor Horsepower:

4 3/4 hp

Headroom:

30 29/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

6,000 lb

Current at Minimum Voltage:

16.4 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

7.9 A

Body Finish:

Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
